73
HCD-DZ100K/DZ500KF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IPODI/O KEY
R607 1-216-841-11 METAL CHIP 47K 5% 1/10W
R608 1-216-841-11 METAL CHIP 47K 5% 1/10W
R609 1-216-817-11 METAL CHIP 470 5% 1/10W
R610 1-216-817-11 METAL CHIP 470 5% 1/10W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R614 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R615 1-216-841-11 METAL CHIP 47K 5% 1/10W
R616 1-216-841-11 METAL CHIP 47K 5% 1/10W
R617 1-216-821-11 METAL CHIP 1K 5% 1/10W
R618 1-216-833-11 METAL CHIP 10K 5% 1/10W
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-821-11 METAL CHIP 1K 5% 1/10W
R623 1-216-841-11 METAL CHIP 47K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R626 1-216-841-11 METAL CHIP 47K 5% 1/10W
R627 1-216-841-11 METAL CHIP 47K 5% 1/10W
R628 1-216-841-11 METAL CHIP 47K 5% 1/10W
R630 1-216-841-11 METAL CHIP 47K 5% 1/10W
R631 1-216-841-11 METAL CHIP 47K 5% 1/10W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R633 1-216-833-11 METAL CHIP 10K 5% 1/10W
R634 1-216-845-11 METAL CHIP 100K 5% 1/10W
R635 1-216-841-11 METAL CHIP 47K 5% 1/10W
R636 1-216-864-11 SHORT CHIP 0
R637 1-216-864-11 SHORT CHIP 0
R638 1-216-821-11 METAL CHIP 1K 5% 1/10W
R639 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R641 1-216-864-11 SHORT CHIP 0
R644 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R645 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R646 1-216-833-11 METAL CHIP 10K 5% 1/10W
R650 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R651 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R652 1-216-809-11 METAL CHIP 100 5% 1/10W
R653 1-216-845-11 METAL CHIP 100K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R657 1-216-809-11 METAL CHIP 100 5% 1/10W
R658 1-216-833-11 METAL CHIP 10K 5% 1/10W
R660 1-216-809-11 METAL CHIP 100 5% 1/10W
R661 1-216-833-11 METAL CHIP 10K 5% 1/10W
R663 1-216-845-11 METAL CHIP 100K 5% 1/10W
R664 1-216-845-11 METAL CHIP 100K 5% 1/10W
R674 1-216-833-11 METAL CHIP 10K 5% 1/10W
R675 1-216-833-11 METAL CHIP 10K 5% 1/10W
R679 1-216-833-11 METAL CHIP 10K 5% 1/10W
R688 1-216-833-11 METAL CHIP 10K 5% 1/10W
R690 1-216-837-11 METAL CHIP 22K 5% 1/10W
R693 1-216-864-11 SHORT CHIP 0
************************************************************
IPOD BOARD
***********
< CAPACITOR >
C636 1-216-864-11 SHORT CHIP 0
C637 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C638 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C639 1-126-964-11 ELECT 10uF 20% 50V
C640 1-126-964-11 ELECT 10uF 20% 50V
C641 1-126-933-11 ELECT 100uF 20% 16V
C642 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C643 1-126-933-11 ELECT 100uF 20% 16V
C646 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< IC >
IC605 8-759-649-89 IC MC4558CD
< JACK >
J603 1-566-822-51 JACK (AUDIO IN)
< RESISTOR >
R605 1-216-817-11 METAL CHIP 470 5% 1/10W
R621 1-216-864-11 SHORT CHIP 0
R642 1-216-864-11 SHORT CHIP 0
R643 1-216-864-11 SHORT CHIP 0
R665 1-216-817-11 METAL CHIP 470 5% 1/10W
R666 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R667 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R668 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R669 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R670 1-216-821-11 METAL CHIP 1K 5% 1/10W
R671 1-216-821-11 METAL CHIP 1K 5% 1/10W
R672 1-216-821-11 METAL CHIP 1K 5% 1/10W
R673 1-216-821-11 METAL CHIP 1K 5% 1/10W
R677 1-216-845-11 METAL CHIP 100K 5% 1/10W
R678 1-216-845-11 METAL CHIP 100K 5% 1/10W
R683 1-216-864-11 SHORT CHIP 0
R684 1-216-864-11 SHORT CHIP 0
************************************************************
KEY BOARD
*********
< RESISTOR >
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S802 1-762-875-21 SWITCH, KEYBOARD (B)
S803 1-762-875-21 SWITCH, KEYBOARD (.)
S804 1-762-875-21 SWITCH, KEYBOARD (X)
S805 1-762-875-21 SWITCH, KEYBOARD (x )
S806 1-762-875-21 SWITCH, KEYBOARD (>)
S807 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S808 1-762-875-21 SWITCH, KEYBOARD (A)
************************************************************
