82
HCD-DZ100K/DZ500KF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN MIC
R764 1-216-809-11 METAL CHIP 100 5% 1/10W
R765 1-216-809-11 METAL CHIP 100 5% 1/10W
R774 1-216-821-11 METAL CHIP 1K 5% 1/10W
R775 1-216-841-11 METAL CHIP 47K 5% 1/10W
R789 1-216-809-11 METAL CHIP 100 5% 1/10W
R790 1-216-809-11 METAL CHIP 100 5% 1/10W
R791 1-216-809-11 METAL CHIP 100 5% 1/10W
R792 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R793 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(DZ500KF)
R793 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ100K)
0R901 1-219-759-11 METAL 1M 5% 1/2W
0R903 1-215-929-11 METAL OXIDE 100K 5% 3W
0R904 1-215-929-11 METAL OXIDE 100K 5% 3W
0R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R908 1-260-105-11 CARBON 3.3K 5% 1/2W
0R909 1-216-845-11 METAL CHIP 100K 5% 1/10W
0R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0R912 1-216-363-00 METAL OXIDE 0.33 5% 2W
0R914 1-214-789-00 METAL 0.1 10% 5W
0R918 1-216-864-11 SHORT CHIP 0
0R919 1-216-836-11 METAL CHIP 18K 5% 1/10W
0R920 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R921 1-215-904-61 METAL OXIDE 100K 5% 2W
0R922 1-216-793-11 METAL CHIP 4.7 5% 1/10W
0R923 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0R924 1-216-864-11 SHORT CHIP 0
0R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0R926 1-216-855-11 METAL CHIP 680K 5% 1/10W
0R927 1-216-349-00 METAL OXIDE 1 5% 1W
0R929 1-249-478-11 CARBON 2.2 5% 1/2W
0R930 1-216-864-11 SHORT CHIP 0
R931 1-218-863-11 METAL CHIP 4.7K 0.50% 1/10W
(DZ100K)
R931 1-218-869-11 METAL CHIP 8.2K 0.50% 1/10W
(DZ500KF)
R932 1-218-883-11 METAL CHIP 33K 0.50% 1/10W
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-218-859-11 METAL CHIP 3.3K 0.50% 1/10W
R940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R941 1-216-864-11 SHORT CHIP 0
R943 1-216-864-11 SHORT CHIP 0
R946 1-216-811-11 METAL CHIP 150 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R952 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
R953 1-218-861-11 METAL CHIP 3.9K 0.50% 1/10W
R954 1-216-837-11 METAL CHIP 22K 5% 1/10W
R955 1-216-817-11 METAL CHIP 470 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB505 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
< TRANSFORMER >
0 T901 1-443-651-11 TRANSFORMER, CONVERTER
0 T902 1-443-650-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
< VIBRATOR >
X450 1-795-660-21 QUARTZ CRYSTAL UNIT (49.152MHz)
X500 1-795-843-11 VIBRATOR, CRYSTAL (12.288MHz)
X501 1-813-325-11 VIBRATOR, CRYSTAL (13.90MHz)
X502 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
************************************************************
MIC BOARD
*********
< CAPACITOR >
C621 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C632 1-125-972-91 ELECT 100uF 20% 16V
C633 1-125-972-91 ELECT 100uF 20% 16V
C644 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C653 1-124-464-11 ELECT 0.22uF 20% 50V
C659 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C660 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C667 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C668 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C671 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN604 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D601 8-719-988-61 DIODE 1SS355TE-17
D602 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB601 1-469-144-21 FERRITE, EMI (SMD) (2012)
