83
HCD-DZ100K/DZ500KF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC604 8-759-649-89 IC MC4558CD
< JACK >
J602 1-566-891-21 JACK (MIC)
< RESISTOR >
R647 1-216-833-11 METAL CHIP 10K 5% 1/10W
R676 1-216-833-11 METAL CHIP 10K 5% 1/10W
R681 1-216-845-11 METAL CHIP 100K 5% 1/10W
R682 1-216-821-11 METAL CHIP 1K 5% 1/10W
R686 1-216-864-11 SHORT CHIP 0
R687 1-216-821-11 METAL CHIP 1K 5% 1/10W
R689 1-216-833-11 METAL CHIP 10K 5% 1/10W
R691 1-216-835-11 METAL CHIP 15K 5% 1/10W
R692 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
(CHUCKING/TRAY DETECT)
************************************************************
STBY BOARD
**********
< CONNECTOR >
CN804 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (`/1)
*************************************************************
MISCELLANEOUS
*************
4 A-1074-643-A TUNER UNIT (DTP-005)
5 1-787-331-11 FAN, D.C.
7 1-828-952-11 WIRE (FLAT TYPE) (9 CORE)
0 9 1-828-528-11 CORD, POWER
57 1-828-361-11 WIRE (FLAT TYPE) (19 CORE)
105 1-830-550-11 WIRE (FLAT TYPE) (24 CORE)
106 1-830-546-11 WIRE (FLAT TYPE) (11 CORE) (80mm)
110 1-830-464-11 WIRE (FLAT TYPE) (23 CORE)
112 1-830-549-11 WIRE (FLAT TYPE) (5 CORE)
113 1-830-545-11 WIRE (FLAT TYPE) (11 CORE) (200mm)
114 1-830-548-11 WIRE (FLAT TYPE) (13 CORE)
0 507 8-820-290-02 OPTICAL PICK-UP KHM-310CAA/C2RP
0 F901 1-532-506-33 FUSE (T6.3AL/250V)
************************************************************
