101
HCD-EA20
Ref. No. Part No. Description Remarks
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
R674 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R675 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R676 1-216-833-11 METAL CHIP 10K 5% 1/16W
R677 1-216-833-11 METAL CHIP 10K 5% 1/16W
R681 1-216-813-11 METAL CHIP 220 5% 1/16W
R682 1-216-833-11 METAL CHIP 10K 5% 1/16W
R683 1-216-833-11 METAL CHIP 10K 5% 1/16W
R684 1-216-841-11 METAL CHIP 47K 5% 1/16W
R685 1-216-845-11 METAL CHIP 100K 5% 1/16W
R687 1-216-841-11 METAL CHIP 47K 5% 1/16W
R688 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC 5MHz
************************************************************
MISCELLANEOUS
**************
57 1-773-039-11 WIRE (FLAT TYPE) (17 CORE)
102 1-775-267-11 WIRE (FLAT TYPE) (29 CORE)
0 107 1-575-651-21 CORD, POWER
108 1-763-697-21 DC FAN (AEP,UK)
108 1-787-094-11 FAN, DC (RU)
109 1-500-386-21 FILTER, CLAMP (FERRITE CORE)
116 1-773-989-11 WIRE (FLAT TYPE) (5 CORE)
118 1-775-152-11 WIRE (FLAT TYPE) (17 CORE)
119 1-775-083-11 WIRE (FLAT TYPE) (9 CORE)
120 1-827-627-11 WIRE (FLAT TYPE) (15 CORE)
121 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
122 1-775-102-11 WIRE (FLAT TYPE) (11 CORE)
123 1-775-189-11 WIRE (FLAT TYPE) (21 CORE)
403 1-773-983-11 WIRE (FLAT TYPE)(5 CORE)
407 1-689-264-11 PWB, FLEXIBLE (24 CORE)
0 408 1-477-263-11 OPTICAL PICK-UP (TDP022W)
0 F902 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F903 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 T101 1-443-067-11 TRANSFORMER, POWER
