NOTE:
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
SECTION 7
EXPLODED VIEWS
80
HCD-EA20
• The mechanical parts with no reference
number in the exploded views are not supplied.
•Abbreviation
RU : Russian model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-1. CASE SECTION
1
2
2
#1
#1
chassis section
front panel section
1 4-249-698-01 CASE
2 3-363-099-11 SCREW (CASE 3 TP2)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
