15
HCD-EA20
3-8. DVD MECHANISM (CDM77A-DVBU20)
3-9. TRAY (AU)
4
tray (AU)
3
two claws
bottom side
1
2
6
two claws
7
CD lid
4
w
ire (flat type)
5core (CN001)
5
w
ire (flat type)
29p (CN002)
3
three screws
(sumitite 3
×
6)
8
DVD mechanism
(CDM77A-DVBU20)
1
two screws
(+BVTP2.6
×
8)
2
cover
