Sony HCD-EA20 - Front Panel Section; Panel Board, Standby Board

11
HCD-EA20
3-2. FRONT PANEL SECTION
3-3. PANEL BOARD, STANDBY BOARD
1 connector
(CN401)
4 three screws
(+BVTP3 × 8)
6 front panel section
5 two claws
2 w ire (flat type)
17core (CN601)
3 chassis groun
d
4 five screws
(BVTP2.6
× 8)
3 two screws
(BVTP2.6
× 8
)
8 front panel assy
1 vol knob
5 w ire (flat type)
17core (CN801)
6 STANDBY board
7 PANEL board
2 nut
