Sony HCD-EA20 - 6-3. Printed Wiring Board - RF Section -

3434
HCD-EA20
6-3. PRINTED WIRING BOARD – RF SECTION – • See page 27 for Circuit Boards Location.
• : Uses unleaded solder.
Ref. No. Location
D001 C-11
D002 B-11
IC001 D-11
Q001 C-3
Q002 B-3
• Semiconductor
Location
(SIDE A)
RF BOARD
(SIDE B)
RF BOARD
IC001
TO
DMB03 BOARD
CN501
D
E
E
OPTICAL PICK-UP
BLOCK
(TDP022W)
1-684-822-
11
(11)
1-684-822-
11
(11)
1
16
17 32
48
33
64 49
1 2 3 4 5 6 7 8 9 10 11 12 13
A
B
C
D
E
F
(Page 37)
