HCD-EA20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
STANDBY
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C037 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR,FFC(LIF(NON-ZIF))29P
CN003 1-784-861-21 CONNECTOR, FFC(LIF(NON-ZIF))9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-551-01 IC CXD1881AR
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/16W
R004 1-216-803-11 METAL CHIP 33 5% 1/16W
R005 1-216-841-11 METAL CHIP 47K 5% 1/16W
R006 1-216-817-11 METAL CHIP 470 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-841-11 METAL CHIP 47K 5% 1/16W
R010 1-216-817-11 METAL CHIP 470 5% 1/16W
R011 1-216-864-11 METAL CHIP 0 5% 1/16W
R012 1-216-864-11 METAL CHIP 0 5% 1/16W
R013 1-216-864-11 METAL CHIP 0 5% 1/16W
R014 1-216-864-11 METAL CHIP 0 5% 1/16W
R015 1-216-864-11 METAL CHIP 0 5% 1/16W
R016 1-216-864-11 METAL CHIP 0 5% 1/16W
R017 1-216-864-11 METAL CHIP 0 5% 1/16W
R018 1-216-864-11 METAL CHIP 0 5% 1/16W
R019 1-216-864-11 METAL CHIP 0 5% 1/16W
R020 1-216-864-11 METAL CHIP 0 5% 1/16W
R021 1-216-864-11 METAL CHIP 0 5% 1/16W
R022 1-216-813-11 METAL CHIP 220 5% 1/16W
R023 1-216-820-11 METAL CHIP 820 5% 1/16W
R024 1-216-864-11 METAL CHIP 0 5% 1/16W
R025 1-216-809-11 METAL CHIP 100 5% 1/16W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 METAL CHIP 0 5% 1/16W
R028 1-216-864-11 METAL CHIP 0 5% 1/16W
R029 1-216-864-11 METAL CHIP 0 5% 1/16W
R032 1-216-809-11 METAL CHIP 100 5% 1/16W
R033 1-216-864-11 METAL CHIP 0 5% 1/16W
R034 1-219-570-11 METAL CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/16W
R041 1-216-821-11 METAL CHIP 1K 5% 1/16W
************************************************************
1-689-809-11 STANDBY BOARD
**************
< CAPACITOR >
C808 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C832 1-126-795-11 ELECT 10uF 20.00% 50V
< DIODE >
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-300-71 DIODE SEL2210R-TP6
< IC >
IC801 8-759-826-34 IC NJL74H400A ( )
< RESISTOR >
R804 1-216-821-11 METAL CHIP 1K 5% 1/16W
R810 1-216-805-11 METAL CHIP 47 5% 1/16W
R835 1-216-805-11 METAL CHIP 47 5% 1/16W
< SWITCH >
S831 1-786-220-11 SWITCH, KEY BOARD (POWER)
************************************************************
A-4748-523-A SUB TRANSFORMER BOARD, COMPLETE
*********************************
< CAPACITOR >
0 C905 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C911 1-126-768-11 ELECT 2200uF 20.00% 16V
C912 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
RF SUB TRANSFORMER
