97
HCD-EA20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C817 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C819 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C820 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C821 1-126-795-11 ELECT 10uF 20.00% 50V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-126-795-11 ELECT 10uF 20.00% 50V
C824 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C827 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C828 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C829 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C830 1-126-791-11 ELECT 10uF 20.00% 16V
C833 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C834 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C835 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C836 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C837 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C838 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C839 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C876 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
< DIODE >
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-988-61 DIODE 1SS355TE-17
D809 8-719-988-61 DIODE 1SS355TE-17
D810 8-719-421-24 DIODE MA8039-H-TX
D885 8-719-058-24 DIODE RB501V-40TE-17
D887 8-719-058-24 DIODE RB501V-40TE-17
< FERRITE BEAD >
FB800 1-216-295-91 SHORT CHIP 0
FB801 1-414-813-11 FERRITE 0uH
FB802 1-216-295-91 SHORT CHIP 0
FB851 1-500-284-21 FERRITE 0uH
< FILTER >
FL801 1-518-932-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC802 8-759-643-83 IC PT6315
< JACK >
J851 1-794-453-11 JACK (PHONES)
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L812 1-410-997-42 INDUCTOR 2.2uH
L813 1-410-997-42 INDUCTOR 2.2uH
< TRANSISTOR >
Q803 8-729-808-42 TRANSISTOR 2SD1624T-TD-E
Q804 8-729-808-42 TRANSISTOR 2SD1624T-TD-E
Q881 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q882 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
< RESISTOR >
R812 1-216-821-11 METAL CHIP 1K 5% 1/16W
R813 1-216-821-11 METAL CHIP 1K 5% 1/16W
R814 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R822 1-216-821-11 METAL CHIP 1K 5% 1/16W
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R840 1-216-844-11 METAL CHIP 82K 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R846 1-216-845-11 METAL CHIP 100K 5% 1/16W
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R855 1-216-809-11 METAL CHIP 100 5% 1/16W
R874 1-216-839-11 METAL CHIP 33K 5% 1/16W
R879 1-216-809-11 METAL CHIP 100 5% 1/16W
R881 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R882 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
S811 1-786-220-11 SWITCH, KEY BOARD (FUNCTION)
S812 1-786-220-11 SWITCH, KEY BOARD (H)
S813 1-786-220-11 SWITCH, KEY BOARD (X)
S814 1-786-220-11 SWITCH, KEY BOARD (x)
S821 1-786-220-11 SWITCH, KEY BOARD (A)
S822 1-786-220-11 SWITCH, KEY BOARD (NEXT > / +)
S823 1-786-220-11 SWITCH, KEY BOARD (. PREV / -)
< TRANSFORMER >
T801 1-443-068-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR(POSITIVE) >
THP801 1-804-046-11 THERMISTOR, POSITIVE (RXE030)
************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
PANEL RF
