Sony HCD-EA20 - Printed Wiring Board; Loading Section

3636
HCD-EA20
6-5. PRINTED WIRING BOARD – LOADING SECTION – • See page 27 for Circuit Boards Location.
• : Uses unleaded solder.
6-6. SCHEMATIC DIAGRAM – LOADING SECTION –
(DISC IN/OUT)
(LOADING)
TO
UCOM
BOARD
CN654
(Page 47)
M
MS-128
S001
JL001
JL002
JL003
JL004
JL005
CN001
5P
CN654
(Page 48)
