12
HCD-EA20
3-4. UCOM BOARD
5
connector
(CN653)
4
connector
(CN652)
3
connector
(CN651)
2
w
ire (flat type)
5core (CN654)
1
w
ire (flat type)
17core (CN601)
6
w
ire (flat type)
11core (CN621)
8
w
ire (flat type)
5core (CN611)
7
w
ire (flat type)
17core(CN631)
q;
UCOM board
9
four screws
(+BVTP3
×
8)
3-5. DMB03 BOARD
5
connector
(CN102)
6
w
ire (flat type)
21core (CN107)
7
w
ire (flat type)
5core (CN101)
8
w
ire (flat type)
15core (CN105)
4
w
ire (flat type)
29core (CN501)
9
DMB03 board
1
two screws
(+BVTP3
×
8)
2
two screws
(+BVTP3
×
8)
3
heat sink
