17
HCD-EA20
3-12. OPTICAL PICK-UP (TDP022W)
3
w
ire (flat type)
24p (CN001)
2
flexible board
(CN003)
5
three step screws (M)
8
optical pick-up
(TDP022W)
1
claw
6
holder (DVU1)
7
three insulators
4
RF board
