99
HCD-EA20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C913 1-104-665-11 ELECT 100uF 20.00% 10V
C914 1-126-960-11 ELECT 1uF 20.00% 50V
C915 1-126-947-11 ELECT 47uF 20.00% 16V
C916 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
< CONNECTOR >
CN901 1-774-108-11 PIN, CONNECTOR (PC BOARD)
CN902 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 6-500-522-11 DIODE 10EDB40-TA2B5
D915 6-500-522-11 DIODE 10EDB40-TA2B5
< IC >
IC911 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q901 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
< RESISTOR >
R902 1-216-845-11 METAL CHIP 100K 5% 1/16W
R903 1-216-819-11 METAL CHIP 680 5% 1/16W
R904 1-247-791-91 CARBON 22 5% 1/4W
R911 1-216-835-11 METAL CHIP 15K 5% 1/16W
R912 1-216-839-11 METAL CHIP 33K 5% 1/16W
R913 1-216-845-11 METAL CHIP 100K 5% 1/16W
R914 1-216-837-11 METAL CHIP 22K 5% 1/16W
R916 1-216-845-11 METAL CHIP 100K 5% 1/16W
< RELAY >
RY901 1-755-467-11 RELAY (POWER)
< TRANSFORMER >
0 T901 1-437-730-11 TRANSFORMER, POWER
************************************************************
A-4748-528-A UCOM BOARD, COMPLETE (AEP,UK)
*****************************
A-4750-132-A UCOM BOARD, COMPLETE (RU)
**************************
< CAPACITOR >
C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C504 1-126-934-11 ELECT 220uF 20.00% 10V
C511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C512 1-126-963-11 ELECT 4.7uF 20.00% 50V
C516 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C523 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C528 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C529 1-126-947-11 ELECT 47uF 20.00% 16V
C530 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C536 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C572 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C594 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C595 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C596 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C604 1-126-947-11 ELECT 47uF 20.00% 16V
C606 1-216-864-11 METAL CHIP 0 5% 1/16W
C607 1-216-864-11 METAL CHIP 0 5% 1/16W
C609 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C651 1-126-934-11 ELECT 220uF 20.00% 10V
C652 1-126-934-11 ELECT 220uF 20.00% 10V
C653 1-126-933-11 ELECT 100uF 20.00% 16V
C654 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C655 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C656 1-126-934-11 ELECT 220uF 20.00% 10V
C657 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C658 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C659 1-126-934-11 ELECT 220uF 20.00% 10V
C660 1-126-935-11 ELECT 470uF 20.00% 10V
C661 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C662 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C663 1-126-933-11 ELECT 100uF 20.00% 16V
C664 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C665 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C666 1-126-933-11 ELECT 100uF 20.00% 16V
C667 1-126-933-11 ELECT 100uF 20.00% 16V
C671 1-126-933-11 ELECT 100uF 20.00% 16V
C672 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C675 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C676 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C677 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C681 1-104-905-11 CAPACITOR 0.22F 5.5V
C682 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C683 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C685 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C688 1-126-963-11 ELECT 4.7uF 20.00% 50V
< CONNECTOR >
CN601 1-784-778-11 CONNECTOR, FFC 17P
CN602 1-779-275-11 CONNECTOR, FFC(LIF(NON-ZIF))7P
CN611 1-779-273-11 CONNECTOR, FFC(LIF(NON-ZIF))5P
CN621 1-779-279-11 CONNECTOR,FFC(LIF(NON-ZIF))11P
CN631 1-779-285-11 CONNECTOR,FFC(LIF(NON-ZIF))17P
CN651 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN652 1-764-333-11 PLUG, CONNECTOR 10P
* CN653 1-564-715-11 PIN, CONNECTOR (SMALL TYPE)13P
CN654 1-779-273-11 CONNECTOR, FFC(LIF(NON-ZIF))5P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-988-61 DIODE 1SS355TE-17
D612 8-719-988-61 DIODE 1SS355TE-17
D651 8-719-210-33 DIODE EC10DS2-TE12L5
D652 8-719-210-33 DIODE EC10DS2-TE12L5
D683 8-719-988-61 DIODE 1SS355TE-17
D684 8-719-988-61 DIODE 1SS355TE-17
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
