HCD-EA20
– UCOM BOARD – – PANEL BOARD –
– I/O BOARD –
qf IC501 qg (X2)
200 ns
3.1 Vp-p
1 V/DIV, 100 ns/DIV
10 V/DIV, 4 µ s/DIV
qg Q803 collector
8.0 µ s
24.4 Vp-p
H
2.7 Vp-p
H
2.0 Vp-p
H
2.7 Vp-p
qh IC252 ea (VOUTb) qj IC252 ed (COUT)
1 V/DIV, 20 µ s/DIV 1 V/DIV, 20 µ s/DIV
ql IC251 2 (OUT)
1 V/DIV, 20 µ s/DIV
w; IC291 qf (XO)
231 ns
3.3 Vp-p
1 V/DIV, 100 ns/DIV
qk IC252 wk (YOUTb)
1 V/DIV, 20 µ s/DIV
2.2 Vp-p
H
qh to ql :Color bars video signal
