86
HCD-EA20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AMP
IC501 8-759-385-17 IC NJM4580E(TE2)
IC502 8-759-539-45 IC M62429P
IC521 8-759-385-17 IC NJM4580E(TE2)
IC522 8-759-539-45 IC M62429P
IC551 8-759-385-17 IC NJM4580E(TE2)
IC552 8-759-539-45 IC M62429P
IC951 6-701-021-01 IC SI-8120JF
IC952 8-759-474-09 IC SI-8050S-LF1101
IC953 6-700-813-01 IC SI-8033JF
< JACK >
J301 1-694-919-11 TERMINAL BOARD (6CH SPEAKER)
< COIL >
L341 1-420-872-52 COIL, AIR-CORE
L342 1-420-872-52 COIL, AIR-CORE
L343 1-420-872-52 COIL, AIR-CORE
L391 1-420-872-52 COIL, AIR-CORE
L392 1-420-872-52 COIL, AIR-CORE
L441 1-420-872-52 COIL, AIR-CORE
L491 1-420-872-52 COIL, AIR-CORE
L901 1-414-398-11 INDUCTOR 10uH
L902 1-414-398-11 INDUCTOR 10uH
L951 1-456-419-11 INDUCTOR 120uH
L952 1-456-419-11 INDUCTOR 120uH
L953 1-456-419-11 INDUCTOR 120uH
< TRANSISTOR >
Q321 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q322 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q323 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q331 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q332 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q371 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q372 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q381 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q382 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q383 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q401 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q411 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q424 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q425 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q426 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q461 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q462 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q463 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q472 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q473 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q474 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q476 8-729-921-73 TRANSISTOR 2SD1781K-T146-QR
Q477 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
Q478 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q479 8-729-016-79 TRANSISTOR 2SC2412KLN-T146-E
Q511 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q512 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q521 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q522 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q551 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q552 8-729-422-35 TRANSISTOR 2SC3624A-T1L15
Q972 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R301 1-216-821-11 METAL CHIP 1K 5% 1/16W
R302 1-216-841-11 METAL CHIP 47K 5% 1/16W
R303 1-216-841-11 METAL CHIP 47K 5% 1/16W
R304 1-216-841-11 METAL CHIP 47K 5% 1/16W
R305 1-216-841-11 METAL CHIP 47K 5% 1/16W
R306 1-216-818-11 METAL CHIP 560 5% 1/16W
R307 1-216-818-11 METAL CHIP 560 5% 1/16W
R308 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R309 1-245-605-51 FUSIBLE 100 5% 1/4W
0 R310 1-245-605-51 FUSIBLE 100 5% 1/4W
R311 1-216-833-11 METAL CHIP 10K 5% 1/16W
R313 1-216-833-11 METAL CHIP 10K 5% 1/16W
R321 1-216-821-11 METAL CHIP 1K 5% 1/16W
R322 1-216-835-11 METAL CHIP 15K 5% 1/16W
R323 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R324 1-208-602-11 METAL 0.22 2W
R325 1-249-625-31 CARBON 10 5% 1/2W
R326 1-216-821-11 METAL CHIP 1K 5% 1/16W
R327 1-216-835-11 METAL CHIP 15K 5% 1/16W
R328 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R329 1-208-602-11 METAL 0.22 2W
R330 1-249-625-31 CARBON 10 5% 1/2W
R331 1-216-821-11 METAL CHIP 1K 5% 1/16W
R332 1-216-835-11 METAL CHIP 15K 5% 1/16W
R333 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R334 1-208-602-11 METAL 0.22 2W
R335 1-249-625-31 CARBON 10 5% 1/2W
R337 1-216-833-11 METAL CHIP 10K 5% 1/16W
R338 1-216-841-11 METAL CHIP 47K 5% 1/16W
R339 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R340 1-215-865-11 METAL OXIDE 220 5% 1W
R341 1-247-791-91 CARBON 22 5% 1/4W
R342 1-247-791-91 CARBON 22 5% 1/4W
R343 1-247-791-91 CARBON 22 5% 1/4W
R344 1-247-791-91 CARBON 22 5% 1/4W
R345 1-247-791-91 CARBON 22 5% 1/4W
R346 1-247-791-91 CARBON 22 5% 1/4W
R347 1-247-791-91 CARBON 22 5% 1/4W
R348 1-247-791-91 CARBON 22 5% 1/4W
R349 1-247-791-91 CARBON 22 5% 1/4W
R350 1-247-791-91 CARBON 22 5% 1/4W
R351 1-216-821-11 METAL CHIP 1K 5% 1/16W
R352 1-216-821-11 METAL CHIP 1K 5% 1/16W
R353 1-216-821-11 METAL CHIP 1K 5% 1/16W
R354 1-216-841-11 METAL CHIP 47K 5% 1/16W
R355 1-216-841-11 METAL CHIP 47K 5% 1/16W
R356 1-216-841-11 METAL CHIP 47K 5% 1/16W
R357 1-216-819-11 METAL CHIP 680 5% 1/16W
R358 1-216-819-11 METAL CHIP 680 5% 1/16W
R359 1-216-819-11 METAL CHIP 680 5% 1/16W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
