95
HCD-EA20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C163 1-126-795-11 ELECT 10uF 20.00% 50V
C164 1-126-795-11 ELECT 10uF 20.00% 50V
C168 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C169 1-126-795-11 ELECT 10uF 20.00% 50V
C170 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C171 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C191 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C192 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C201 1-128-551-11 ELECT 22uF 20.00% 25V
C202 1-128-551-11 ELECT 22uF 20.00% 25V
C211 1-126-795-11 ELECT 10uF 20.00% 50V
C212 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C213 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C214 1-126-795-11 ELECT 10uF 20.00% 50V
C215 1-126-795-11 ELECT 10uF 20.00% 50V
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C222 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C223 1-128-551-11 ELECT 22uF 20.00% 25V
C224 1-128-551-11 ELECT 22uF 20.00% 25V
C225 1-128-551-11 ELECT 22uF 20.00% 25V
C226 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C227 1-128-551-11 ELECT 22uF 20.00% 25V
C228 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C229 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C252 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C254 1-126-933-11 ELECT 100uF 20.00% 16V
C255 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C256 1-126-795-11 ELECT 10uF 20.00% 50V
C257 1-128-551-11 ELECT 22uF 20.00% 25V
C258 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C266 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C268 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C269 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C272 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C273 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C292 1-126-963-11 ELECT 4.7uF 20.00% 50V
C293 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
C294 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C295 1-164-380-11 CERAMIC CHIP 51PF 5.00% 50V
C296 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C297 1-126-947-11 ELECT 47uF 20.00% 16V
C298 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C299 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< CONNECTOR >
CN101 1-779-554-21 CONNECTOR,FFC(LIF(NON-ZIF))17P
CN102 1-779-546-11 CONNECTOR, FFC(LIF(NON-ZIF))9P
CN103 1-779-552-21 CONNECTOR,FFC(LIF(NON-ZIF))15P
CN104 1-784-733-11 CONNECTOR, FFC 11P
< DIODE >
D291 8-719-056-78 DIODE UDZSTE-174.3B
< FERRITE BEAD >
FB121 1-412-002-31 INDUCTOR 4.7uH
FB151 1-500-284-21 FERRITE 0uH
FB221 1-412-002-31 INDUCTOR 4.7uH
< IC >
IC101 8-759-385-17 IC NJM4580E(TE2)
IC106 8-759-284-49 IC NJM2285V-TE2
IC111 8-759-385-17 IC NJM4580E(TE2)
IC121 8-759-385-76 IC MC14052 BDR2
IC151 8-759-696-10 IC NJM2235V(TE2)
IC251 6-702-334-01 IC MM1510XNRE
IC252 6-702-335-01 IC MM1568AJBE
IC291 8-759-557-36 IC BU1924F-E2
< JACK >
J101 1-816-039-11 JACK, PIN 3P (VIDEO OUT/AUDIO OUT)
J102 1-817-876-11 JACK, PIN 3P (VIDEO IN/AUDIO IN)
J171 1-817-877-11 JACK, PIN 2P (AUDIO IN)
J251 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
< JUMPER RESISTOR >
JW251 1-216-864-11 METAL CHIP 0 5% 1/16W
JW253 1-216-864-11 METAL CHIP 0 5% 1/16W
JW254 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L152 1-469-525-91 INDUCTOR 10uH
L251 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q103 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q112 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q121 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q122 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q123 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q203 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q212 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q221 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q251 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q252 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q291 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
< RESISTOR >
R102 1-216-817-11 METAL CHIP 470 5% 1/16W
R103 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R104 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R105 1-216-841-11 METAL CHIP 47K 5% 1/16W
R106 1-216-845-11 METAL CHIP 100K 5% 1/16W
R107 1-216-821-11 METAL CHIP 1K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R111 1-216-821-11 METAL CHIP 1K 5% 1/16W
R113 1-216-845-11 METAL CHIP 100K 5% 1/16W
R114 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R115 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R116 1-216-833-11 METAL CHIP 10K 5% 1/16W
R117 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R118 1-216-818-11 METAL CHIP 560 5% 1/16W
R119 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R120 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R121 1-216-845-11 METAL CHIP 100K 5% 1/16W
R122 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
