43
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C531 1-162-851-11 CERAMIC 0.1uF 10% 16V
C532 1-130-495-00 MYLAR 0.1uF 5% 50V
C538 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C539 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C540 1-101-004-00 CERAMIC 0.01uF 50V
C541 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C542 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C543 1-126-937-11 ELECT 4700uF 20% 16V
C999 1-162-851-11 CERAMIC 0.1uF 10% 16V
< CONNECTOR >
M501 1-784-040-11 CONNECTOR, BOARD TO BOARD 19P
* M502 1-564-674-11 PIN, CONNECTOR 8P
* M503 1-506-984-11 PIN, CONNECTOR (PC BOARD) 2P
* M504 1-568-790-11 PIN, CONNECTOR 13P
< DIODE >
D1 8-719-991-33 DIODE 1SS133T-77
D2 8-719-937-56 DIODE RLS-73-TE-11
D3 8-719-031-85 DIODE 1N4002L
D4 8-719-991-33 DIODE 1SS133T-77
D502 8-719-067-67 DIODE W02G
D503 8-719-921-88 DIODE MTZJ-T-77-13B
D504 8-719-110-31 DIODE MTZJ-T-77-12C
D506 8-719-053-18 DIODE 1SR154-400TE-25
D507 8-719-110-03 DIODE MTZJ-T-77-7.5C
D515 8-719-077-63 DIODE 1N5402
D516 8-719-077-63 DIODE 1N5402
D517 8-719-077-63 DIODE 1N5402
D518 8-719-077-63 DIODE 1N5402
D519 8-719-053-18 DIODE 1SR154-400TE-25
D520 8-719-053-18 DIODE 1SR154-400TE-25
< FUSE >
! F501 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5) (4A/125V)
(US,CND)
! F501 1-532-237-00 FUSE (T3.15A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
! F502 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5) (4A/125V)
(US,CND)
! F502 1-532-237-00 FUSE (T3.15A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
! F503 1-532-742-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,CND)
! F503 1-532-259-00 FUSE (T1.6A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
! F504 1-532-742-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,CND)
! F504 1-532-259-00 FUSE (T1.6A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
! F505 1-532-742-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,CND)
! F505 1-532-259-00 FUSE (T1.6A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
! F506 1-532-742-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,CND)
! F506 1-532-259-00 FUSE (T1.6A/250V)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
< IC >
IC501 8-759-701-57 IC NJM78M06FA
IC505 8-759-288-53 IC LA5617
< COIL >
L1 1-420-872-00 COIL, AIR CORE (AEP,UK,MY,SP,HK,KR,TW,AUS)
L2 1-420-872-00 COIL, AIR CORE (AEP,UK,MY,SP,HK,KR,TW,AUS)
< TRANSISTOR >
Q1 8-729-200-36 TRANSISTOR 2SA966-Y
Q2 8-729-201-53 TRANSISTOR 2SA1015TP-GR
Q3 8-729-201-53 TRANSISTOR 2SA1015TP-GR
Q4 8-729-265-52 TRANSISTOR 2SC2655-Y(TPE6)
Q6 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q501 8-729-230-49 TRANSISTOR 2SC2712G-TE85L
Q502 8-729-216-22 TRANSISTOR 2SA1162G-TE85L
Q503 8-729-201-53 TRANSISTOR 2SA1015TP-GR
Q504 8-729-209-15 TRANSISTOR 2SD2012
Q505 8-729-017-51 TRANSISTOR 2SB632K-E
Q506 8-729-281-53 TRANSISTOR 2SC1815-GR
Q507 8-729-188-23 TRANSISTOR 2SD882-P
Q508 8-729-188-23 TRANSISTOR 2SD882-P
Q510 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R22 1-249-429-11 CARBON 10K 5% 1/4W
R23 1-216-073-00 METAL CHIP 10K 5% 1/10W
R24 1-249-437-11 CARBON 47K 5% 1/4W
R25 1-216-073-00 METAL CHIP 10K 5% 1/10W
R26 1-216-081-00 METAL CHIP 22K 5% 1/10W
R27 1-249-441-11 CARBON 100K 5% 1/4W
R28 1-216-097-91 RES,CHIP 100K 5% 1/10W
R29 1-247-887-00 CARBON 220K 5% 1/4W
R31 1-249-417-11 CARBON 1K 5% 1/4W F
R32 1-247-863-91 CARBON 22K 5% 1/4W
R33 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R34 1-249-417-11 CARBON 1K 5% 1/4W F
R35 1-216-081-00 METAL CHIP 22K 5% 1/10W
R36 1-247-843-11 CARBON 3.3K 5% 1/4W
R37 1-216-085-00 METAL CHIP 33K 5% 1/10W
R38 1-249-425-11 CARBON 4.7K 5% 1/4W F
R39 1-249-425-11 CARBON 4.7K 5% 1/4W F
R40 1-249-389-11 CARBON 4.7 5% 1/4W F
R41 1-249-389-11 CARBON 4.7 5% 1/4W F
R42 1-216-081-00 METAL CHIP 22K 5% 1/10W
R43 1-216-081-00 METAL CHIP 22K 5% 1/10W
R44 1-216-089-91 RES,CHIP 47K 5% 1/10W
R45 1-216-083-00 METAL CHIP 27K 5% 1/10W
R46 1-216-033-00 METAL CHIP 220 5% 1/10W
R47 1-216-085-00 METAL CHIP 33K 5% 1/10W
R48 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R49 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R50 1-249-386-11 CARBON 2.7 5% 1/6W F
(AEP,UK,MY,SP,HK,KR,TW,AUS)
POWER AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
To Next Page
