Sony HCD-ED2 - Page 44

44
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
RDS
R51 1-249-386-11 CARBON 2.7 5% 1/6W F
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R30A 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R30B 1-216-298-00 METAL CHIP 2.2 5% 1/10W
! R501 1-216-373-11 METAL OXIDE 2.2 5% 2W F
! R502 1-216-355-11 METAL OXIDE 3.3 5% 1W F
R503 1-249-429-11 CARBON 10K 5% 1/4W
R504 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R505 1-216-081-00 METAL CHIP 22K 5% 1/10W
R506 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-216-089-91 RES,CHIP 47K 5% 1/10W
R508 1-216-089-91 RES,CHIP 47K 5% 1/10W
R509 1-216-025-91 RES,CHIP 100 5% 1/10W
R510 1-215-869-11 METAL OXIDE 1K 5% 1W F
R511 1-247-863-91 CARBON 22K 5% 1/4W
R512 1-216-077-91 RES,CHIP 15K 5% 1/10W
R515 1-215-860-11 METAL OXIDE 33 5% 1W F
R516 1-216-049-91 RES,CHIP 1K 5% 1/10W
! R517 1-216-355-11 METAL OXIDE 3.3 5% 1W F
R518 1-216-041-00 METAL CHIP 470 5% 1/10W
< RESISTOR >
RX1 1-216-025-91 RES,CHIP 100 5% 1/10W
< RELAY >
RY1 1-755-067-11 RELAY
RY501 1-755-067-11 RELAY
< TERMINAL >
TM501 1-694-645-11 TERMINAL, SPEAKER
**************************************************************
1-676-338-11 POWER IC BOARD
***************
< IC >
IC5 8-759-333-24 IC LM1876TF
**************************************************************
A-4428-110-A RDS BOARD, COMPLETE
********************
(AEP,UK,MY,SP,HK,KR,TW,AUS)
A-4428-246-A RDS BOARD, COMPLETE (US,CND)
********************
< CAPACITOR >
C401 1-162-294-31 CERAMIC 0.001uF 10% 50V
C402 1-162-294-31 CERAMIC 0.001uF 10% 50V
C403 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C404 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C405 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C421 1-124-589-11 ELECT 47uF 20% 16V
C423 1-126-157-11 ELECT 10uF 20% 16V
C451 1-124-257-00 ELECT 2.2uF 20% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C452 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C453 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C454 1-126-157-11 ELECT 10uF 20% 16V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C455 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C456 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
C457 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP,UK,MY,SP,HK,KR,TW,AUS)
< CONNECTOR >
M401 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
M451 1-784-776-11 CONNECTOR, FFC 15P
< IC >
IC451 8-759-450-86 IC BU1922 (AEP,UK,MY,SP,HK,KR,TW,AUS)
< CO2IL >
L401 1-410-521-11 INDUCTOR 100uH
L402 1-410-521-11 INDUCTOR 100uH
L403 1-410-521-11 INDUCTOR 100uH
L404 1-410-521-11 INDUCTOR 100uH
L405 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q450 8-729-620-05 TRANSISTOR 2SC2603TP-EF
(AEP,UK,MY,SP,HK,KR,TW,AUS)
< RESISTOR >
R401 1-249-417-11 CARBON 1K 5% 1/4W F
R402 1-249-417-11 CARBON 1K 5% 1/4W F
R403 1-247-807-31 CARBON 100 5% 1/4W
R404 1-247-807-31 CARBON 100 5% 1/4W
R405 1-247-807-31 CARBON 100 5% 1/4W
R406 1-247-807-31 CARBON 100 5% 1/4W
R408 1-249-429-11 CARBON 10K 5% 1/4W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R409 1-249-417-11 CARBON 1K 5% 1/4W F
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R410 1-249-429-11 CARBON 10K 5% 1/4W
R411 1-249-429-11 CARBON 10K 5% 1/4W
R452 1-259-880-11 CARBON 2.2M 5% 1/4W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R453 1-249-417-11 CARBON 1K 5% 1/4W F
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R454 1-247-815-91 CARBON 220 5% 1/4W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
R455 1-247-815-91 CARBON 220 5% 1/4W
(AEP,UK,MY,SP,HK,KR,TW,AUS)
POWER AMP POWER IC
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
