Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X451 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
(AEP,UK,MY,SP,HK,KR,TW,AUS)
**************************************************************
A-4428-106-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C210 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C211 1-126-935-11 ELECT 470uF 20% 16V
C214 1-124-997-11 ELECT 470uF 20% 10V
C217 1-101-004-00 CERAMIC 0.01uF 50V
C218 1-126-927-11 ELECT 2200uF 20% 10V
C229 1-101-001-00 CERAMIC 0.001uF 50V
C235 1-124-234-00 ELECT 22uF 20% 16V
C236 1-124-234-00 ELECT 22uF 20% 16V
C241 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C242 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C245 1-162-851-11 CERAMIC 0.1uF 10% 16V
C246 1-126-767-11 ELECT 1000uF 20% 16V
C650 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C651 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C652 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C653 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C654 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C655 1-124-589-11 ELECT 47uF 20% 16V
C797 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C798 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C799 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN102 1-770-167-11 CONNECTOR, FFC/FPC 19P
CN601 1-791-970-11 CORD (197-2P/PH)
M3011 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
M3012 1-573-845-11 CONNECTOR, BOARD TO BOARD 13P
M7031 1-573-845-11 CONNECTOR, BOARD TO BOARD 13P
M7032 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D200 8-719-031-85 DIODE 1N4002L
D206 8-719-031-85 DIODE 1N4002L
D207 8-719-031-85 DIODE 1N4002L
D213 8-719-991-33 DIODE 1SS133T-77
D214 8-719-991-33 DIODE 1SS133T-77
D215 8-719-991-33 DIODE 1SS133T-77
D217 8-719-929-15 DIODE RD9.1ESB2
D650 8-719-110-31 DIODE RD12ESB2
D651 8-719-110-31 DIODE RD12ESB2
D652 8-719-991-33 DIODE 1SS133T-77
D770 8-719-031-85 DIODE 1N4002L
D771 8-719-031-85 DIODE 1N4002L
< IC >
IC650 8-759-925-80 IC SN74HC14ANS-E05
IC651 8-759-925-90 IC SN74HC74ANS-E05
< COIL >
L202 1-410-517-11 INDUCTOR 47uH
< TRANSISTOR >
Q202 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q203 8-729-200-36 TRANSISTOR 2SA966-Y
Q204 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q205 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q770 8-729-200-36 TRANSISTOR 2SA966-Y
Q771 8-729-200-36 TRANSISTOR 2SA966-Y
Q772 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q773 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R206 1-216-075-00 METAL CHIP 12K 5% 1/10W
R207 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R213 1-216-025-91 RES,CHIP 100 5% 1/10W
R214 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R215 1-216-025-91 RES,CHIP 100 5% 1/10W
R216 1-216-025-91 RES,CHIP 100 5% 1/10W
R218 1-216-025-91 RES,CHIP 100 5% 1/10W
R219 1-216-025-91 RES, CHIP 100 5% 1/10W
R220 1-216-025-91 RES,CHIP 100 5% 1/10W
R224 1-216-073-00 METAL CHIP 10K 5% 1/10W
R225 1-216-073-00 METAL CHIP 10K 5% 1/10W
R231 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R232 1-216-093-91 RES,CHIP 68K 5% 1/10W
R233 1-216-073-00 METAL CHIP 10K 5% 1/10W
R234 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R235 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R236 1-216-073-00 METAL CHIP 10K 5% 1/10W
! R237 1-215-860-11 METAL OXIDE 33 5% 1W F
R653 1-216-073-00 METAL CHIP 10K 5% 1/10W
R654 1-247-807-31 CARBON 100 5% 1/4W
R655 1-247-807-31 CARBON 100 5% 1/4W
R656 1-249-441-11 CARBON 100K 5% 1/4W
R657 1-216-099-00 METAL CHIP 120K 5% 1/10W
R774 1-249-430-11 CARBON 12K 5% 1/4W
R775 1-249-430-11 CARBON 12K 5% 1/4W
R776 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R777 1-249-418-11 CARBON 1.2K 5% 1/4W F
R231A 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R231B 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R233A 1-216-073-00 METAL CHIP 10K 5% 1/10W
< FLAT CABLE >
W103 1-784-039-21 CONNECTOR, BOARD TO BOARD 19P
W201 1-793-886-11 CONNECTOR (197-E310-07)
W202 1-793-887-11 CONNECTOR (197-E310-14)
W203 1-793-888-11 CONNECTOR (197-E310-25)
W704 1-691-071-31 HOUSING, CONNECTOR 12P
**************************************************************
RELAY
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
