Sony HCD-EX1 - Motor Assy and Cam Disassembly; Base Unit Disassembly

11
3-5. MOTOR ASSY AND CAM
3-6. BASE UNIT
1
2
3
4
5
6
7
8
9
0
!¡
!™
!£
!¢
!∞
!§
Slider (3)
Slider (2)
Diskholder
Lever (1)
Mecha cover
Motor assy
SW cam
Two screws (BVTP2.6x8)
Two screws
(
BVTP2.6x8
)
Two screws (BVTP2.6x8)
Two screws (BVTP2.6x8)
Screws (BTP2.6x8)
Screws (PTPWH2.6x?)
Two screws (2.4x6)
Two screws (2.4x6)
Cam
1
2
3
4
5
6
7
8
9
0
!™
!£
!¢
!∞
!¡
Two screws (BVTP2.6x8)
Two screws
(BVTP2.6x8
)
Guide (L)
Guide (R)
Slider (4)
Slider (4)
Slider (1)
Two screws (PTPWH2.6)
Screws (PTPWH2.6)
Two screws (PTPWH2.6)
Two screws
(PTPWH2.6)
Coil spring
Coil spring
BU holder
Pick up assy
Note: Adjustment of the phase is required in assembly.Refer to
"Section 1. Servicing Note" for details.
