Sony HCD-EX1 - Main and Power Board Disassembly

12
3-7. MAIN BOARD AND POWER BOARD
Two screws
(BVTT3x5)
Two screws
(BVTP3x8)
Two screws
(BVTP3x8)
Three screws
(BVTT3x5)
Two screws
(BVTT3x5)
Screw (PTPWH2.6)
Screw (BVTT3x5)
Screw (BVTT3x5)
Screw (BVTT3x5
)
Main board
Power board
Power cord
REG board
Connector
POWER board: CN903
Back panel
1
2
3
4
Two screws
(BVTT3x5)
Screw (BVTT3x5)
Sealed case
Spacer
Flat type wire
(13 core)
Flat type wire (7 core)
5
6
7
8
9
0
!¡
!™
!£
!¢
!∞
!§
!¶
!•
!ª
@º
@¡
