Sony HCD-EX1 - Page 35

35
Pin No.
Pin Name
I/O
Function
51 to 54 COM0 to COM3 O LCD COMMON
55 BIAS O LCD DRIVE POWER
56 to 58 VLC0 to VLC2 O LCD DRIVER POWER
59 VSS0 O Ground
60 to 99 SEG0 to SEG39 O FL segment signal output
100 STEREO I ST STEREO
