37
HCD-EX200
6-2. CHASSIS SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
#1
#1
#1
#1
#1
#1
#1
#3
#3
#3
#3
#3
#3
#3
#1
#1
#1
#1
#1
#3
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
54
55
57
58
64
61
62
56
70
67
69
69
68
51
63
51
59
53
71
LCD701
52
70
60
51 3-314-903-01 CUSHION
52 4-234-982-01 HOLDER, LCD
53 A-4725-965-A AMP BOARD, COMPLETE
54 A-4725-964-A POWER BOARD, COMPLETE
55 A-4725-969-A REG BOARD, COMPLETE
56 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
* 57 3-703-244-00 BUSHING (2104), CORD
58 4-222-730-21 PANEL, BACK
59 A-4727-800-A MAIN BOARD, COMPLETE
060 1-783-531-31 CORD, POWER
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
61 1-682-074-11 LED BOARD
62 1-791-698-11 WIRE (FLAT TYPE) (16 CORE)
63 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
64 1-693-407-13 TUNER
* 67 4-028-047-01 HEAT SINK, CLIP TYPE
68 4-224-741-01 INSULATED PLATE (POWER.2)
69 4-224-740-01 INSULATED PLATE (POWER.1)
* 70 3-344-749-01 RETAINER (B)
71 3-561-427-11 CUSHION
LCD701 1-804-474-11 DISPLAY PANEL, LIQUID CRYSTAL
