HCD-EX200
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 7
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
A-4725-965-A AMP BOARD, COMPLETE
******************
< CAPACITOR >
C801 1-126-047-71 ELECT 4.7uF 20% 50V
C803 1-126-022-11 ELECT 47uF 20% 25V
C804 1-162-219-31 CERAMIC 68PF 5% 50V
C805 1-164-159-11 CERAMIC 0.1uF 50V
C806 1-164-159-11 CERAMIC 0.1uF 50V
C807 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C811 1-126-027-11 ELECT 1000uF 20% 25V
C812 1-126-027-11 ELECT 1000uF 20% 25V
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C821 1-126-933-11 ELECT 100uF 20% 16V
C822 1-126-967-11 ELECT 47uF 20% 50V
C851 1-126-047-71 ELECT 4.7uF 20% 50V
C853 1-126-022-11 ELECT 47uF 20% 25V
C854 1-162-219-31 CERAMIC 68PF 5% 50V
C855 1-164-159-11 CERAMIC 0.1uF 50V
C856 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN801 1-568-943-11 PIN, CONNECTOR 5P
CN802 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
* CN810 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D821 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC801 8-759-333-24 IC LM1876TF
< COIL >
L801 1-420-872-00 COIL, AIR-CORE
L851 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q821 8-729-900-53 TRANSISTOR DTC114EK
Q822 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q823 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q824 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-216-088-00 METAL CHIP 43K 5% 1/10W
R803 1-249-417-11 CARBON 1K 5% 1/4W
R804 1-249-436-11 CARBON 39K 5% 1/4W
R805 1-249-754-11 CARBON 10 5% 1/2W
R806 1-249-393-11 CARBON 10 5% 1/4W
R807 1-216-089-91 RES-CHIP 47K 5% 1/10W
R821 1-216-085-91 RES-CHIP 33K 5% 1/10W
R822 1-216-091-00 METAL CHIP 56K 5% 1/10W
0R823 1-247-739-11 CARBON 100 5% 1/2W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-216-088-00 METAL CHIP 43K 5% 1/10W
R853 1-249-417-11 CARBON 1K 5% 1/4W
R854 1-249-436-11 CARBON 39K 5% 1/4W
R855 1-249-754-11 CARBON 10 5% 1/2W
R856 1-249-393-11 CARBON 10 5% 1/4W
R857 1-216-091-00 METAL CHIP 56K 5% 1/10W
< RELAY >
RY801 1-755-170-11 RELAY (12V)
******************************************************
1-682-076-11 EJECT BOARD
***********
< CAPACITOR >
C650 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C652 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C653 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C654 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C656 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< DIODE >
D650 8-719-069-56 DIODE UDZSTE-176.2B
D651 8-719-069-56 DIODE UDZSTE-176.2B
< IC >
IC651 8-759-673-48 IC SN74HC14ANSR
IC652 8-759-925-90 IC SN74HC74ANSR
