HCD-GNX780/GNX880
Pin No. Pin Name I/O Description
99 EXCK I SBSO readout clock input
100 XRST I System reset signal input from M30622MEP
101 SYSM I Muting signal input (Connected to ground)
102 DATA I Serial data input from M30622MEP
103 VSS – Ground terminal
104 XLAT I Latch signal input from M30622MEP
105 CLOCK I Serial data transfer clock input from M30622MEP
106 VDD – Power supply terminal (+2.5V)
107 SENS O SENS output to M30622MEP
108 SCLK I SENS serial data readout clock input (Connected to +VDD(+3.3v))
109 ATSK I/O Not used (Open)
110WFCK O WFCK output
111 XUGF O Not used (Open)
112XPCK O Not used (Open)
113 GFS O Not used (Open)
114C2PO O Not used (Open)
115 SCOR O High output when the sub code sync, S0 or S1, is detected
116 VDD – Power supply terminal (+2.5V)
117 C4M O Not used (Open)
118 WDCK O Not used (Open)
119 COUT I/O Not used (Open)
120 NC – Not used (Open)
