HCD-HPR90/HPR99XM
10
3-6. FRONT PANEL SECTION, CD MECHANICAL (DLM5B)
3
four screws
(BVTP3
×
8)
2
screw
(BVTT3
×
6)
4
5
chassi
1
three screws
(B3)
A
B
6
Turn the lower gear in the direction of the arrow
A
,
untill the upper gear gose up to the high position.
7
Draw out the tray fully in the
direction of the arrow
B
.
8
two claws
9
lid (CD)
upper gear
q;
front panel section
qa
CD mechanical
(DLM5B)
