Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
61
HCD-HPR90/HPR99XM
MAIN
C1526 1-126-960-11 ELECT 1uF 20% 50V
(HPR99XM)
C1531 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1532 1-126-933-11 ELECT 100uF 20% 16V
C1550 1-126-934-11 ELECT 220uF 20% 16V
C1552 1-126-933-11 ELECT 100uF 20% 16V
C1555 1-126-964-11 ELECT 10uF 20% 50V
C1558 1-126-964-11 ELECT 10uF 20% 50V
C1559 1-126-960-11 ELECT 1uF 20% 50V
C1561 1-126-964-11 ELECT 10uF 20% 50V
C1562 1-126-960-11 ELECT 1uF 20% 50V
C1563 1-126-960-11 ELECT 1uF 20% 50V
C1565 1-126-964-11 ELECT 10uF 20% 50V
C1567 1-126-934-11 ELECT 220uF 20% 16V
C1576 1-126-960-11 ELECT 1uF 20% 50V
(HPR99XM)
C1603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1613 1-126-934-11 ELECT 220uF 20% 16V
C1614 1-126-960-11 ELECT 1uF 20% 50V
(HPR90)
C1614 1-126-964-11 ELECT 10uF 20% 50V
(HPR99XM)
C1615 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1616 1-126-934-11 ELECT 220uF 20% 16V
C1628 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1629 1-126-934-11 ELECT 220uF 20% 16V
C1635 1-126-934-11 ELECT 220uF 20% 16V
C1636 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1664 1-126-960-11 ELECT 1uF 20% 50V
(HPR90)
C1664 1-126-964-11 ELECT 10uF 20% 50V
(HPR99XM)
C1665 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN1203 1-815-443-11 PIN, CONNECTOR (PWB) 2P
CN1205 1-819-131-11 PIN, CONNECTOR 3P (HPR99XM)
CN1301 1-784-776-11 CONNECTOR, FFC 15P (HPR99XM)
CN1302 1-784-780-11 CONNECTOR, FFC 19P
CN1305 1-568-830-11 CONNECTOR, FFC 11P
CN1306 1-568-828-11 CONNECTOR, FFC 9P
CN1307 1-815-450-11 PIN, CONNECTOR (PWB) 9P
CN1308 1-784-776-11 CONNECTOR, FFC 15P
CN1309 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN1310 1-568-828-11 CONNECTOR, FFC 9P
< DIODE >
D1201 8-719-000-07 DIODE MC2836
D1202 8-719-000-07 DIODE MC2836
D1203 8-719-000-07 DIODE MC2836
D1204 8-719-000-07 DIODE MC2836
D1205 6-501-193-01 DIODE 1SS355WTE-17 (HPR99XM)
D1206 8-719-063-79 DIODE 1N4002B
D1207 8-719-063-79 DIODE 1N4002B
D1208 8-719-063-79 DIODE 1N4002B
D1209 8-719-063-79 DIODE 1N4002B
D1210 8-719-063-79 DIODE 1N4002B
D1211 8-719-063-79 DIODE 1N4002B
D1212 8-719-063-79 DIODE 1N4002B
D1213 8-719-063-79 DIODE 1N4002B
D1303 8-719-000-07 DIODE MC2836
D1305 6-501-193-01 DIODE 1SS355WTE-17
< EARTH TERMINAL >
EP1201 1-537-771-21 TERMINAL BOARD, GROUND
EP1202 1-537-771-21 TERMINAL BOARD, GROUND
< IC/TRANSISTOR >
IC1201 8-759-647-17 IC uPC2912HF
IC1202 8-759-701-59 IC NJM78M09FA
IC1203 6-703-546-01 IC TA7804LS
IC1204 6-707-282-01 IC MM1615ANLE
IC1205 8-759-071-48 IC TA7807S
IC1301 6-806-303-01 IC M30624MGP-A58FPU0 (HPR99XM)
IC1301 6-806-619-11 IC M30622MEP-A39FPU0 (HPR90)
IC1302 6-701-680-01 IC PST3629NR
IC1501 6-701-824-11 IC BD3870FS-E2
IC1502 8-759-656-83 IC NJM4580MD- (TE2)
IC1503 6-551-484-01 TRANSISTOR RT3C55M-TP-1B
IC1504 6-551-484-01 TRANSISTOR RT3C55M-TP-1B
IC1505 8-759-430-37 IC MC14052BDTR2 (HPR99XM)
< JUMPER RESISTOR >
JR1001 1-216-864-11 SHORT CHIP 0
JR1002 1-216-864-11 SHORT CHIP 0
JR1003 1-216-864-11 SHORT CHIP 0
JR1004 1-216-864-11 SHORT CHIP 0
JR1005 1-216-864-11 SHORT CHIP 0
JR1006 1-216-864-11 SHORT CHIP 0
JR1007 1-216-864-11 SHORT CHIP 0
JR1008 1-216-864-11 SHORT CHIP 0
JR1009 1-216-864-11 SHORT CHIP 0
JR1010 1-216-864-11 SHORT CHIP 0
JR1011 1-216-864-11 SHORT CHIP 0
JR1012 1-216-864-11 SHORT CHIP 0
JR1013 1-216-864-11 SHORT CHIP 0
JR1014 1-216-864-11 SHORT CHIP 0
JR1501 1-216-864-11 SHORT CHIP 0 (HPR90)
JR1502 1-216-864-11 SHORT CHIP 0 (HPR90)
JR1503 1-216-864-11 SHORT CHIP 0
JR1614 1-216-864-11 SHORT CHIP 0
JR1618 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q1301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1501 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1502 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q1503 8-729-027-43 TRANSISTOR DTC114EKA-T146
(HPR99XM)
Q1504 8-729-027-43 TRANSISTOR DTC114EKA-T146
(HPR99XM)
Q1505 8-729-027-43 TRANSISTOR DTC114EKA-T146
(HPR99XM)
Q1508 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1509 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q1510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
