HCD-HPR90/HPR99XM
9
3-4. MAIN BOARD
3-5. AMP BOARD, POWER BOARD SECTION
6
two screws (B3)
qa
MAIN boar
7
5
two connectors
(CN32, CN604)
5
connector
(CN1203)
3
flexible flat (15 core) cable
(CN1308)
4
flexible flat (19 core) cable
(CN1302)
1
flexible flat (9 core) cable
(CN1306)
9
flexible flat (9 core) cable
(CN1310)
2
flexible flat (11 core) cable
(CN1305)
q;
flexible flat (15 core) cable
(HPR99XM model)
(CN1301)
8
flexible flat (23 core) cable
(CN1309)
5
connector
(HPR99XM model)
(CN1205)
1
screw
(B3)
1
screw
(B3)
2
3
AMP board,
POWER board section
