Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
60
HCD-HPR90/HPR99XM
HP A-INFL
< RESISTOR >
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R905 1-216-845-11 METAL CHIP 100K 5% 1/10W
R906 1-216-853-11 METAL CHIP 470K 5% 1/10W
R907 1-216-809-11 METAL CHIP 100 5% 1/10W
R908 1-216-809-11 METAL CHIP 100 5% 1/10W
R909 1-216-809-11 METAL CHIP 100 5% 1/10W
R910 1-216-845-11 METAL CHIP 100K 5% 1/10W
R911 1-216-845-11 METAL CHIP 100K 5% 1/10W
R921 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R922 1-216-833-11 METAL CHIP 10K 5% 1/10W
R923 1-216-809-11 METAL CHIP 100 5% 1/10W
R924 1-216-809-11 METAL CHIP 100 5% 1/10W
R925 1-216-864-11 SHORT CHIP 0
R926 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
T921 1-443-953-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-1167-362-A HP A-IN BOARD, COMPLETE
***********************
< CAPACITOR >
C982 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C984 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C986 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C987 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C989 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C990 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C997 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C999 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< JUMPER RESISTOR >
FB981 1-216-864-11 SHORT CHIP 0
FB982 1-216-864-11 SHORT CHIP 0
FB983 1-216-864-11 SHORT CHIP 0
< JACK >
J981 1-815-603-11 JACK (AUDIO IN)
J982 1-815-603-11 JACK (PHONES)
< RESISTOR >
R931 1-216-821-11 METAL CHIP 1K 5% 1/10W
R932 1-216-845-11 METAL CHIP 100K 5% 1/10W
R941 1-216-821-11 METAL CHIP 1K 5% 1/10W
R942 1-216-845-11 METAL CHIP 100K 5% 1/10W
R981 1-216-833-11 METAL CHIP 10K 5% 1/10W
R982 1-216-837-11 METAL CHIP 22K 5% 1/10W
R983 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S981 1-762-875-21 SWITCH, KEYBOARD (REPEAT/FM MODE)
S982 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
************************************************************
A-1167-363-A MAIN BOARD, COMPLETE (HPR90: US, CND)
A-1167-403-A MAIN BOARD, COMPLETE (HPR99XM)
A-1171-432-A MAIN BOARD, COMPLETE (HPR90: E, E51)
A-1171-456-A MAIN BOARD, COMPLETE (HPR90: AR)
A-1171-473-A MAIN BOARD, COMPLETE (HPR90: SP, AUS)
A-1173-202-A MAIN BOARD, COMPLETE (HPR90: MX)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1201 1-126-943-11 ELECT 2200uF 20% 25V
C1202 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1203 1-126-935-11 ELECT 470uF 20% 16V
C1204 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1205 1-126-935-11 ELECT 470uF 20% 16V
C1206 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1207 1-126-935-11 ELECT 470uF 20% 16V
C1208 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1209 1-126-934-11 ELECT 220uF 20% 16V
C1211 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1212 1-126-935-11 ELECT 470uF 20% 16V
C1213 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1214 1-126-935-11 ELECT 470uF 20% 16V
C1217 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1218 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1301 1-126-916-11 ELECT 1000uF 20% 6.3V
C1310 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1311 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1316 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1362 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1403 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1404 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1502 1-126-934-11 ELECT 220uF 20% 16V
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-126-934-11 ELECT 220uF 20% 16V
C1505 1-126-964-11 ELECT 10uF 20% 50V
C1506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(HPR99XM)
C1507 1-126-933-11 ELECT 100uF 20% 16V
(HPR99XM)
C1508 1-126-964-11 ELECT 10uF 20% 50V
C1509 1-126-960-11 ELECT 1uF 20% 50V
C1511 1-126-964-11 ELECT 10uF 20% 50V
C1512 1-126-960-11 ELECT 1uF 20% 50V
C1513 1-126-960-11 ELECT 1uF 20% 50V
C1515 1-126-964-11 ELECT 10uF 20% 50V
C1517 1-126-934-11 ELECT 220uF 20% 16V
C1518 1-130-495-00 MYLAR 0.1uF 5% 50V
C1519 1-130-495-00 MYLAR 0.1uF 5% 50V
C1520 1-130-495-00 MYLAR 0.1uF 5% 50V
C1521 1-130-495-00 MYLAR 0.1uF 5% 50V
C1522 1-130-475-00 MYLAR 0.0022uF 5% 50V
C1523 1-130-475-00 MYLAR 0.0022uF 5% 50V
MAIN
Ver. 1.1
