56
HCD-HPR90/HPR99XM
SECTION 8
ELECTRICAL PARTS LIST
AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1166-890-A AMP BOARD, COMPLETE (HPR90)
A-1183-658-A AMP BOARD, COMPLETE (HPR99XM)
********************
< CAPACITOR >
C701 1-126-961-11 ELECT 2.2uF 20% 50V
C702 1-136-497-11 FILM 0.1uF 5% 50V
C703 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C704 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C706 1-100-717-11 CERAMIC CHIP 1uF 16V
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C711 1-126-934-11 ELECT 220uF 20% 16V
C712 1-100-717-11 CERAMIC CHIP 1uF 16V
C713 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C714 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C715 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C716 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C717 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C718 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C719 1-100-924-21 ELECT 2200uF 20% 35V
C720 1-131-704-11 FILM 1uF 5% 50V
C722 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C723 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C724 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C725 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C726 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C728 1-131-704-11 FILM 1uF 5% 50V
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C731 1-104-665-11 ELECT 100uF 20% 25V
C732 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C733 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C734 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C735 1-126-964-11 ELECT 10uF 20% 50V
C736 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C737 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C738 1-126-964-11 ELECT 10uF 20% 50V
C739 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C740 1-126-934-11 ELECT 220uF 20% 16V
C741 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C742 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C743 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C744 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
AR : Argentina model
AUS: Australian model
CND : Canadian model
C745 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C746 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C747 1-104-665-11 ELECT 100uF 20% 25V
C748 1-126-964-11 ELECT 10uF 20% 50V
C749 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C751 1-126-961-11 ELECT 2.2uF 20% 50V
C752 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-104-665-11 ELECT 100uF 20% 25V
C754 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C756 1-100-717-11 CERAMIC CHIP 1uF 16V
C757 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C758 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C759 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C761 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C762 1-100-717-11 CERAMIC CHIP 1uF 16V
C763 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C764 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C765 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C766 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C767 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C768 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C769 1-100-924-21 ELECT 2200uF 20% 35V
C770 1-131-704-11 FILM 1uF 5% 50V
C772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C773 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C774 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C775 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C777 1-131-704-11 FILM 1uF 5% 50V
C778 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C779 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C782 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C783 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C784 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C785 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C786 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C787 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C788 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C791 1-136-497-11 FILM 0.1uF 5% 50V
C793 1-126-964-11 ELECT 10uF 20% 50V
C794 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C795 1-126-964-11 ELECT 10uF 20% 50V
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
Ver. 1.1
E51 : Chilean and Peruvian models
MX : Mexican model
SP : Singapore model
