Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
66
HCD-HPR90/HPR99XM
SP
< TERMINAL >
TB1 1-695-915-11 TAB (CONTACT)
< THERMISTOR >
0 TH1 1-802-075-11 THERMISTOR, NTC (HPR90: SP, AR, AUS)
0 TH1 1-805-901-11 THERMISTOR, NTC
(HPR90: US, CND, E, E51, MX/HPR99XM)
0 TH2 1-805-901-11 THERMISTOR, NTC
(HPR90: US, CND, E, E51, MX/HPR99XM)
< TAB >
TK3 1-537-771-21 TERMINAL BOARD, GROUND
< VARISTOR >
0 VR001 1-805-481-21 VARISTOR (HPR90: US, CND, MX/HPR99XM)
0 VR002 1-802-094-21 VARISTOR (HPR90: E, E51)
0 VR003 1-802-094-21 VARISTOR (HPR90: E, E51)
************************************************************
SP BOARD
********
< CAPACITOR >
C851 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C852 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C853 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C854 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN850 1-819-130-11 PIN, CONNECTOR 2P
CN870 1-819-130-11 PIN, CONNECTOR 2P
< TERMINAL >
J860 1-537-114-21 TERMINAL BOARD (SPEAKER)
************************************************************
A-1184-933-A XM BOARD, COMPLETE (HPR99XM)
********************
< CAPACITOR >
C001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C006 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-128-993-21 ELECT CHIP 22uF 20% 10V
C010 1-128-993-21 ELECT CHIP 22uF 20% 10V
C011 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C012 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C014 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C015 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C016 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C017 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C018 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C019 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C021 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-128-993-21 ELECT CHIP 22uF 20% 10V
C042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C043 1-124-779-00 ELECT CHIP 10uF 20% 16V
C044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C051 1-128-993-21 ELECT CHIP 22uF 20% 10V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C053 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
C055 1-124-779-00 ELECT CHIP 10uF 20% 16V
C056 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C057 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C061 1-216-864-11 SHORT CHIP 0
C062 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C063 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C064 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C065 1-124-779-00 ELECT CHIP 10uF 20% 16V
C066 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C067 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
CN001 1-793-580-11 CONNECTOR, FFC (LIF (NON-Z1F)) 15P
< DIODE >
D011 6-500-848-01 DIODE MC2840-T112-1
D012 6-500-848-01 DIODE MC2840-T112-1
< JUMPER RESISTOR/FERRITE BEAD >
FB001 1-216-295-00 SHORT CHIP 0
FB002 1-216-295-00 SHORT CHIP 0
FB021 1-216-295-00 SHORT CHIP 0
FB022 1-216-295-00 SHORT CHIP 0
FB041 1-414-813-11 FERRITE, EMI (SMD) (2012)
< IC >
IC001 6-709-251-01 IC F2602E-01-TR
IC041 6-708-476-01 IC AK4384ET-E2
IC051 8-759-656-83 IC NJM4580MD- (TE2)
< CONNECTOR >
J001 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
< COIL >
L001 1-469-523-91 INDUCTOR 2.2uH
L002 1-469-523-91 INDUCTOR 2.2uH
< TRANSISTOR >
Q001 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q003 6-551-248-01 TRANSISTOR NTJS3151PT1G
< RESISTOR >
R001 1-216-845-11 METAL CHIP 100K 5% 1/10W
R002 1-216-845-11 METAL CHIP 100K 5% 1/10W
R003 1-216-845-11 METAL CHIP 100K 5% 1/10W
XM
POWER
Ver. 1.1
