Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
65
HCD-HPR90/HPR99XM
POWER
0 D3 8-719-081-58 DIODE S2V60-TA
(HPR90: US, CND, E, E51, MX/HPR99XM)
0 D11 8-719-979-64 DIODE UF4005/23
0 D14 6-500-567-31 DIODE 10ERB20-TB3
0 D15 6-501-178-01 DIODE UDZW-TE17-15B
0 D16 6-501-178-01 DIODE UDZW-TE17-15B
0 D17 6-500-137-01 DIODE BAT54HT1
D31 8-719-510-09 DIODE D10SC6M
D32 8-719-074-58 DIODE FCH10A10
D33 8-719-982-15 DIODE MTZJ-27B
(HPR90: E, E51, MX, SP, AR, AUS)
D33 8-719-110-69 DIODE RD27ESB4
(HPR90: US, CND/HPR99XM)
0 D602 8-719-073-23 DIODE ST02D-200TA
0 D603 6-500-567-31 DIODE 10ERB20-TB3
D604 6-500-567-31 DIODE 10ERB20-TB3
D652 8-719-071-26 DIODE HZU18B3TRF
< FUSE >
0 F1 1-576-232-51 FUSE (5A/250V)
< FERRITE BEAD >
0 FB11 1-410-397-21 FERRITE 1.1uH
< IC >
0 IC11 6-707-749-01 IC CXD9841P
0 IC601 6-708-726-01 IC MIP2F20MS1SO
IC650 6-705-280-01 IC FAN431AZXA
< COIL >
L602 1-412-525-31 INDUCTOR 10uH
< PHOTO COUPLER >
0 PH11 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
0 PH601 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
0 PH602 6-600-438-01 PHOTO COUPLER TLP421F (D4-GR)
< TRANSISTOR >
0 Q11 6-551-302-11 FET 2SK3561
(HPR90: US, CND/HPR99XM)
0 Q11 6-551-319-01 FET 2SK3563 (LB2SONY)
(HPR90: E, E51, MX, SP, AR, AUS)
0 Q12 6-551-302-11 FET 2SK3561
(HPR90: US, CND/HPR99XM)
0 Q12 6-551-319-01 FET 2SK3563 (LB2SONY)
(HPR90: E, E51, MX, SP, AR, AUS)
0 Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q650 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q652 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
0 R1 1-219-237-11 SOLID 3.3M 20% 1/2W F
(HPR90: US, CND/HPR99XM)
0 R2 1-219-512-11 METAL 2.2M 5% 1/2W F
0 R3 1-219-759-11 METAL 1M 5% 1/2W F
(HPR90: E, E51)
0R4 1-219-759-11 METAL 1M 5% 1/2W F
(HPR90: E, E51)
0R10 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
0R11 1-216-864-11 SHORT CHIP 0
0R12 1-245-502-21 METAL 4.7M 2% 1/4W F
0R13 1-245-502-21 METAL 4.7M 2% 1/4W F
0R14 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
0R15 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
0R16 1-218-823-11 METAL CHIP 100 0.5% 1/10W
0R17 1-211-989-11 METAL CHIP 68 0.5% 1/10W
0R18 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R20 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R22 1-249-417-11 CARBON 1K 5% 1/4W F
0R23 1-219-984-51 METAL 0.1 5% 2W F
0R24 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R25 1-247-694-11 CARBON 33 5% 1/4W F
0R27 1-216-797-11 METAL CHIP 10 5% 1/10W
0R29 1-216-797-11 METAL CHIP 10 5% 1/10W
R32 1-216-821-11 METAL CHIP 1K 5% 1/10W
R33 1-216-817-11 METAL CHIP 470 5% 1/10W
R41 1-216-845-11 METAL CHIP 100K 5% 1/10W
0R603 1-216-852-11 METAL CHIP 390K 5% 1/10W
0R604 1-249-401-11 CARBON 47 5% 1/4W F
0R605 1-216-835-11 METAL CHIP 15K 5% 1/10W
0R606 1-249-381-11 CARBON 1 5% 1/4W F
0R607 1-216-864-11 SHORT CHIP 0
0R608 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R609 1-218-899-11 METAL CHIP 150K 0.5% 1/16W
0R610 1-218-907-11 METAL CHIP 330K 0.5% 1/10W
R651 1-216-821-11 METAL CHIP 1K 5% 1/10W
R652 1-216-817-11 METAL CHIP 470 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R655 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R656 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R657 1-216-805-11 METAL CHIP 47 5% 1/10W
R658 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R659 1-216-821-11 METAL CHIP 1K 5% 1/10W
R660 1-216-821-11 METAL CHIP 1K 5% 1/10W
R661 1-216-833-11 METAL CHIP 10K 5% 1/10W
R662 1-216-833-11 METAL CHIP 10K 5% 1/10W
R663 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
0S1 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (HPR90: E, E51)
< LINE FILTER/TRANSFORMER >
0T1 1-443-941-11 TRANSFORMER, LINE FILTER
(HPR90: SP, AR, AUS)
0T1 1-457-125-11 COIL, LINE FILTER
(HPR90: US, CND, E, E51, MX/HPR99XM)
0T31 1-443-940-11 TRANSFORMER, CONVERTER
(HPR90: US, CND/HPR99XM)
0T31 1-443-943-11 TRANSFORMER, CONVERTER
(HPR90: E, E51, MX, SP, AR, AUS)
0T603 1-443-942-11 TRANSFORMER, DC-DC CONVERTER
Ver. 1.1
