Sony HCD-HPR90 - Page 41

41
HCD-HPR90/HPR99XM
IC704 NJM2871BF18-TE2
5
VIN
4
VOUT
2
GND
3
NOISE
BYPASS
1
CONTROL
BANDGAP
REFERENCE
THERMAL
PROTECTION
IC705 CXD9788AR
12
11
10
9
8
7
6
5
4
3
VSUBC
XVSS
OUTR2
VSSR
OUTR1
VDDR
VSSL
VSSR
OUTL2
OUTL1
VSSL
VDDL
2
1
PWM
CLOCK
GENERATOR
(SECONDARY)
CLOCK
GENERATOR
(PRIMARY)
31
29
25
OVFFLAGL
26
SFLAG
27
INIT
30
S g P
GAIN
CONTROL
INIT/
MUTE
SAMPLING
RATE
CONVERTER
FILTER &
LOW CUT
FILTER
LINER
INTERPOLATOR
∆ Σ
48
XFSOIN
47
XVDD HPVDDL
46 45
HPOUTL1 HPVSSL
44 43
HPOUTL2 HPVDDR
42 41
HPOUTR1 HPVSSR
40
HPOUTR2
39
37
FSOCKO
38
FSOI
13
XOVSS
14
XFSOOUT
15
XOVDD
16
DVDD
17
DVSS
18
NSPMUTE
19
SOFTMUTE
20
PGMUTE
SERIAL
CONTROLLER
21
SCDT
22
SCSHIFT
23
SCLATCH
24
OVFFLAGR
28
MCKSEL
32
BFVDD
33
BFVSS
34
TEST
35
DVDD
36
XFSIIN
LRCK
BCK
DATA
