Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
60
HCD-L1
R202 1-216-833-11 METAL CHIP 10K 5% 1/16W
R203 1-216-845-11 METAL CHIP 100K 5% 1/16W
R204 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R205 1-216-821-11 METAL CHIP 1K 5% 1/16W
R206 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R207 1-216-857-11 METAL CHIP 1M 5% 1/16W
R212 1-216-813-11 METAL CHIP 220 5% 1/16W
R213 1-216-864-11 METAL CHIP 0 5% 1/16W
R214 1-216-864-11 METAL CHIP 0 5% 1/16W
R215 1-216-864-11 METAL CHIP 0 5% 1/16W
R218 1-216-821-11 METAL CHIP 1K 5% 1/16W
R219 1-216-821-11 METAL CHIP 1K 5% 1/16W
R220 1-216-864-11 METAL CHIP 0 5% 1/16W
R221 1-216-813-11 METAL CHIP 220 5% 1/16W
R222 1-216-813-11 METAL CHIP 220 5% 1/16W
R224 1-216-813-11 METAL CHIP 220 5% 1/16W
R225 1-216-813-11 METAL CHIP 220 5% 1/16W
R226 1-216-809-11 METAL CHIP 100 5% 1/16W
R227 1-216-839-11 METAL CHIP 33K 5% 1/16W
R228 1-216-849-11 METAL CHIP 220K 5% 1/16W
R229 1-216-819-11 METAL CHIP 680 5% 1/16W
R230 1-216-864-11 METAL CHIP 0 5% 1/16W
R237 1-216-809-11 METAL CHIP 100 5% 1/16W
R239 1-216-809-11 METAL CHIP 100 5% 1/16W
R240 1-216-864-11 METAL CHIP 0 5% 1/16W
R250 1-216-841-11 METAL CHIP 47K 5% 1/16W
R299 1-216-864-11 METAL CHIP 0 5% 1/16W
< RES NETWORK >
RN201 1-233-576-11 RES, CHIP NETWORK 100
RN202 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-223-997-21 RES, CARBON ADJ VAR 47K
************************************************************
A-4728-106-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C600 1-125-623-11 DOUBLE LAYER 0.22uF 5.5V
C601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C612 1-107-726-11 CERAMIC CHIP 0.01uF 10% 25V
C619 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C620 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C634 1-164-505-11 CERAMIC CHIP 2.2uF 25V
C635 1-216-864-11 METAL CHIP 0 5% 1/16W
C636 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C637 1-126-960-11 ELECT 1uF 20.00% 50V
C640 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C643 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C644 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C645 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C646 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C658 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C674 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C676 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C677 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C678 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C693 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1401 1-126-048-81 ELECT 10uF 20.00% 50V
C1402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1403 1-126-048-81 ELECT 10uF 20.00% 50V
C1404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1405 1-126-048-81 ELECT 10uF 20.00% 50V
C1406 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1408 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C1409 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C1410 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C1411 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1412 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1413 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1414 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C1421 1-130-467-00 MYLAR 470PF 5% 50V
C1422 1-110-335-11 MYLAR 100PF 5.00% 50V
C1431 1-130-467-00 MYLAR 470PF 5% 50V
C1432 1-110-335-11 MYLAR 100PF 5.00% 50V
< CONNECTOR >
CN600 1-784-859-21 CONNECTOR, FFC(LIF(NON-ZIF))7P
CN601 1-784-834-21 CONNECTOR,FFC(LIF(NON-ZIF))23P
CN604 1-784-774-11 CONNECTOR, FFC 13P
CN1401 1-568-955-11 PIN, CONNECTOR 6P
< DIODE >
D601 8-719-988-61 DIODE 1SS355TE-17
D635 8-719-988-61 DIODE 1SS355TE-17
D1411 8-719-988-61 DIODE 1SS355TE-17
D1412 8-719-988-61 DIODE 1SS355TE-17
D1413 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB601 1-216-864-11 METAL CHIP 0 5% 1/16W
FB637 1-414-813-11 FERRITE 0UH
FB1413 1-500-445-21 FERRITE 0UH
FB1414 1-500-445-21 FERRITE 0UH
< IC >
IC600 6-801-298-01 IC uPD703033AYGF-M35-3BA
IC1400 8-759-825-13 IC PCM1748E/2K
IC1410 8-759-387-77 IC TC7WU04F-TE12L
IC1431 8-759-357-68 IC NJM2115M-TE2
< COIL >
L1401 1-414-754-11 INDUCTOR 10uH
L1411 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q600 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q601 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q602 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q651 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q1411 8-729-027-23 TRANSISTOR DTA114EKA-T146
BD CD
