Sony HCD-L1 - Page 61

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
61
HCD-L1
C MOTOR
< RESISTOR >
R601 1-216-809-11 METAL CHIP 100 5% 1/16W
R602 1-216-025-11 METAL CHIP 100 5% 1/10W
R603 1-216-864-11 METAL CHIP 0 5% 1/16W
R604 1-216-809-11 METAL CHIP 100 5% 1/16W
R605 1-216-864-11 METAL CHIP 0 5% 1/16W
R607 1-216-809-11 METAL CHIP 100 5% 1/16W
R608 1-216-809-11 METAL CHIP 100 5% 1/16W
R609 1-216-025-91 METAL CHIP 100 5% 1/10W
R610 1-216-833-11 METAL CHIP 10K 5% 1/16W
R612 1-216-845-11 METAL CHIP 100K 5% 1/16W
R613 1-216-809-11 METAL CHIP 100 5% 1/16W
R616 1-216-833-11 METAL CHIP 10K 5% 1/16W
R619 1-216-850-11 METAL CHIP 270K 5% 1/16W
R620 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R621 1-216-864-11 METAL CHIP 0 5% 1/16W
R622 1-216-809-11 METAL CHIP 100 5% 1/16W
R623 1-216-833-11 METAL CHIP 10K 5% 1/16W
R632 1-216-809-11 METAL CHIP 100 5% 1/16W
R634 1-216-833-11 METAL CHIP 10K 5% 1/16W
R635 1-216-841-11 METAL CHIP 47K 5% 1/16W
R636 1-216-841-11 METAL CHIP 47K 5% 1/16W
R647 1-216-833-11 METAL CHIP 10K 5% 1/16W
R648 1-216-809-11 METAL CHIP 100 5% 1/16W
R649 1-216-809-11 METAL CHIP 100 5% 1/16W
R672 1-216-833-11 METAL CHIP 10K 5% 1/16W
R677 1-216-821-11 METAL CHIP 1K 5% 1/16W
R678 1-216-821-11 METAL CHIP 1K 5% 1/16W
R679 1-216-833-11 METAL CHIP 10K 5% 1/16W
R680 1-216-833-11 METAL CHIP 10K 5% 1/16W
R681 1-216-833-11 METAL CHIP 10K 5% 1/16W
R684 1-216-833-11 METAL CHIP 10K 5% 1/16W
R685 1-216-833-11 METAL CHIP 10K 5% 1/16W
R686 1-216-833-11 METAL CHIP 10K 5% 1/16W
R687 1-216-833-11 METAL CHIP 10K 5% 1/16W
R688 1-216-833-11 METAL CHIP 10K 5% 1/16W
R691 1-216-809-11 METAL CHIP 100 5% 1/16W
R692 1-216-833-11 METAL CHIP 10K 5% 1/16W
R693 1-216-841-11 METAL CHIP 47K 5% 1/16W
R696 1-216-833-11 METAL CHIP 10K 5% 1/16W
R697 1-216-809-11 METAL CHIP 100 5% 1/16W
R699 1-216-809-11 METAL CHIP 100 5% 1/16W
R1403 1-216-864-11 METAL CHIP 0 5% 1/16W
R1404 1-216-864-11 METAL CHIP 0 5% 1/16W
R1405 1-216-864-11 METAL CHIP 0 5% 1/16W
R1411 1-216-816-11 METAL CHIP 390 5% 1/16W
R1412 1-216-857-11 METAL CHIP 1M 5% 1/16W
R1413 1-216-817-11 METAL CHIP 470 5% 1/16W
R1414 1-216-817-11 METAL CHIP 470 5% 1/16W
R1421 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1422 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1423 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1431 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1432 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1433 1-216-833-11 METAL CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB614 1-233-576-11 RES, CHIP NETWORK 100
RB643 1-233-576-11 RES, CHIP NETWORK 100
RB652 1-233-576-11 RES, CHIP NETWORK 100
RB663 1-233-415-11 RES, CHIP NETWORK 10K (3216)
< VIBRATOR >
X600 1-760-014-31 VIBRATOR, CERAMIC 20 MHz
X1410 1-767-408-21 VIBRETOR, CRYSTAL 16.9344 MHz
************************************************************
A-4728-283-A C MOTOR BOARD, COMPLETE
************************
< CAPACITOR >
C701 1-115-864-11 ELECT 10uF 20.00% 16V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C751 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C752 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN751 1-785-337-11 PIN, CONNECTOR(LIGHT ANGLE)11P
CN752 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE)6P
CN753 1-568-952-11 PIN, CONNECTOR 3P
* CN754 1-568-954-11 PIN, CONNECTOR 5P
* CN755 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D701 8-719-083-57 DIODE UDZSTE-173.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-216-815-11 METAL CHIP 330 5% 1/16W
R702 1-216-805-11 METAL CHIP 47 5% 1/16W
R751 1-216-833-11 METAL CHIP 10K 5% 1/16W
R752 1-216-833-11 METAL CHIP 10K 5% 1/16W
R753 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R754 1-216-833-11 METAL CHIP 10K 5% 1/16W
************************************************************
1-683-912-12 D.SENSOR BOARD
***************
< IC >
IC731 8-749-017-45 SENSOR, PHONT RPR-220C1N
< RESISTOR >
R731 1-216-815-11 METAL CHIP 330 5% 1/16W
R732 1-216-815-11 METAL CHIP 330 5% 1/16W
< SWITCH >
S731 1-786-289-21 SWITCH, DETECTION
************************************************************
CD D.SENSOR
