Sony HCD-L1 - Page 66

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
66
HCD-L1
< COMPOSITION CIRCUIT BLOCK >
RB515 1-233-576-11 RES, CHIP NETWORK 100
< VIBRATOR >
X500 1-760-014-31 VIBRATOR, CERAMIC
X501 1-567-098-41 VIBRATOR, CRYSTAL
X745 1-781-465-21 VIBRATOR, CRYSTAL
************************************************************
A-4728-117-A POWER BOARD, COMPLETE
***********************
< CAPACITOR >
C801 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C802 1-126-024-11 ELECT 220uF 20.00% 25V
C804 1-164-346-11 CERAMIC CHIP 1uF 16V
C805 1-126-926-11 ELECT 1000uF 20.00% 10V
C806 1-164-346-11 CERAMIC CHIP 1uF 16V
C807 1-104-655-11 ELECT 470uF 20.00% 6.3V
C808 1-164-346-11 CERAMIC CHIP 1uF 16V
C810 1-164-346-11 CERAMIC CHIP 1uF 16V
C811 1-126-925-11 ELECT 470uF 20.00% 10V
C812 1-126-024-11 ELECT 220uF 20.00% 25V
C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C822 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C824 1-126-026-11 ELECT 470uF 20.00% 25V
C825 1-126-024-11 ELECT 220uF 20.00% 25V
C826 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN800 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
* CN801 1-564-518-11 PLUG, CONNECTOR 3P
CN802 1-750-199-11 CONNECTOR, BOARD TO BOARD 18P
< DIODE >
D801 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC800 8-759-231-57 IC TA7810S
IC801 8-759-450-49 IC uPC2907HF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-53 IC TA7805S
IC804 8-759-592-79 IC BA00AST-V5
< COIL >
L802 1-412-537-31 INDUCTOR 100uH
L804 1-412-537-31 INDUCTOR 100uH
< TRANSISTOR >
Q800 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q801 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q802 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q803 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q804 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
0 R801 1-219-591-11 FUSIBLE 0.1 5% 1/2W
R802 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R803 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R804 1-216-864-11 METAL CHIP 0 5% 1/16W
R806 1-216-844-11 METAL CHIP 82K 5% 1/16W
R809 1-260-091-11 METAL CHIP 220 5% 1/2W
R810 1-216-821-11 METAL CHIP 1K 5% 1/16W
R812 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R813 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R814 1-216-821-11 METAL CHIP 1K 5% 1/16W
R815 1-218-271-11 RES-CHIP 2.0K 5% 1/16W
R816 1-218-855-11 METAL CHIP 2.2K 5% 1/16W
************************************************************
A-4728-113-A SWITCH BOARD, COMPLETE
***********************
< CAPACITOR >
C1321 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C1331 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C1341 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
< CONNECTOR >
CN1301 1-691-646-11 SOCKET, CONNECTOR 11P
CN1302 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
CN1303 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
CN1321 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE)5P
< DIODE >
D1311 8-719-071-44 DIODE SELS5223C-TP15 (STAND BY)
D1321 8-719-988-61 DIODE 1SS355TE-17
D1322 8-719-988-61 DIODE 1SS355TE-17
D1323 8-719-988-61 DIODE 1SS355TE-17
D1324 8-719-988-61 DIODE 1SS355TE-17
< JACK >
J1321 1-815-736-21 JACK (HEADPHONE)
< LEAD >
CL1321 1-690-880-11 LEAD (WITH CONNECTOR)
< RESISTOR >
R1301 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1302 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1303 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1304 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1311 1-249-417-11 CARBON 1K 5% 1/4W F
R1314 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1315 1-249-433-11 CARBON 22K 5% 1/4W
R1316 1-249-417-11 CARBON 1K 5% 1/4W F
R1317 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1318 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1319 1-249-417-11 CARBON 1K 5% 1/4W F
R1320 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1321 1-249-421-11 CARBON 2.2K 5% 1/4W F
MAIN POWER SWITCH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
