Sony HCD-L1 - Page 67

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
67
HCD-L1
< SWITCH >
S1311 1-762-875-21 SWITCH, KEYBOARD (POWER)
S1313 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1314 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
S1315 1-762-875-21 SWITCH, KEYBOARD (TUNING -)
S1316 1-762-875-21 SWITCH, KEYBOARD (VOL+)
S1317 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S1318 1-762-875-21 SWITCH, KEYBOARD (CD STOP)
S1319 1-762-875-21 SWITCH, KEYBOARD (CD PLAY/PAUSE)
S1320 1-762-875-21 SWITCH, KEYBOARD (VOL-)
S1321 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S1322 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
************************************************************
A-4728-114-A TOUCH SWITCH BOARD, COMPLETE
*****************************
< CAPACITOR >
C1264 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1351 1-124-224-11 ELECT 47uF 20% 6.3V
C1361 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C1363 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C1365 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1366 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< DIODE >
D1361 8-719-069-56 DIODE UDZSTE-176.2B
D1362 8-719-069-56 DIODE UDZSTE-176.2B
D1363 8-719-988-61 DIODE 1SS355TE-17
D1364 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC1351 8-759-826-32 IC NJL72H400A
IC1361 8-759-925-80 IC SN74HC14ANS-E05
IC1362 8-759-925-90 IC SN74HC74ANS-E05
< TRANSISTOR >
Q1361 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1352 1-216-797-11 METAL CHIP 10 5% 1/16W
R1361 1-216-840-11 METAL CHIP 39K 5% 1/16W
R1362 1-216-842-11 METAL CHIP 56K 5% 1/16W
R1363 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1364 1-216-809-11 METAL CHIP 100 5% 1/16W
R1365 1-216-845-11 METAL CHIP 100K 5% 1/16W
R1366 1-216-845-11 METAL CHIP 100K 5% 1/16W
< GROUND >
TS1361 1-694-726-11 TERMINAL, GROUND
************************************************************
MISCELLANEOUS
**************
52 1-769-969-11 WIRE (FLAT TYPE) (13 CORE)
0 54 1-468-654-11 REGULATOR, SWITCHING (US,CND)
0 54 1-468-655-11 REGULATOR, SWITCHING (AEP,UK)
0 54 1-468-656-11 REGULATOR, SWITCHING (SP)
55 1-693-529-51 TUNER (FM/AM) (AEP,UK)
55 1-693-531-11 TUNER (FM/AM) (SP)
55 1-693-534-11 TUNER (FM/AM) (US,CND)
0 59 1-777-071-81 CORD, POWER (UK)
0 59 1-824-023-11 CORD, POWER (AEP,SP)
0 59 1-824-025-11 CORD, POWER (US,CND)
61 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)(US,CND,SP)
61 1-773-001-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
113 1-769-947-11 WIRE (FLAT TYPE) (11 CORE)
FAN101 1-698-997-11 FAN, D.C.
M102 X-4954-294-1 MOTOR ASSY, SLED
M701 1-763-790-11 MOTOR, DC
M711 1-763-790-11 MOTOR, DC
SWITCH TOUCH SWITCH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
