3-9. BASE UNIT (BU-K6BD41A)
1 floating screw
(PTPWHM2.6)
2 base unit
(BU-K6BD41A)
3-10. LOADING BOARD
2 belt (CDM55)
B
3 Pull the tray pushing B .
4 two screws
(BTP2.6
× 6)
5 loading board
1 Rotate the gear(B) in
the direction of arrow
A .
A
