43
HCD-M70
SECTION 8
ELECTRICAL PARTS LIST
CD
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4725-626-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C110 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C111 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C112 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C114 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C115 1-126-382-11 ELECT 100uF 20% 16V
C116 1-126-382-11 ELECT 100uF 20% 16V
C117 1-126-382-11 ELECT 100uF 20% 16V
C118 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C119 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C121 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C122 1-126-382-11 ELECT 100uF 20% 16V
C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C125 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C126 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C127 1-126-382-11 ELECT 100uF 20% 16V
C129 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C130 1-115-156-11 CERAMIC CHIP 1uF 10V
C131 1-124-233-11 ELECT 10uF 20% 16V
C133 1-115-156-11 CERAMIC CHIP 1uF 10V
C140 1-115-156-11 CERAMIC CHIP 1uF 10V
C141 1-115-156-11 CERAMIC CHIP 1uF 10V
C143 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C145 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C146 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C147 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C148 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C153 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C159 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C160 1-124-257-00 ELECT 2.2uF 20% 50V
C162 1-126-382-11 ELECT 100uF 20% 16V
C163 1-126-382-11 ELECT 100uF 20% 16V
C165 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C167 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C168 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C171 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C172 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C181 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C182 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
< CONNECTOR >
CN101 1-691-078-41 HOUSING, CONNECTOR 19P
CN102 1-785-953-11 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD >
FB101 1-469-144-21 FERRITE 0uH
FB102 1-469-144-21 FERRITE 0uH
FB103 1-469-144-21 FERRITE 0uH
FB104 1-469-144-21 FERRITE 0uH
< IC >
IC101 8-752-386-85 IC CXD2587Q
IC102 8-759-549-28 IC BA5974FP-E2
IC103 8-752-085-51 IC CXA2568M-T6
< COIL >
L101 1-410-993-11 INDUCTOR CHIP 1uH
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/10W
R102 1-216-845-11 METAL CHIP 100K 5% 1/10W
R103 1-216-835-11 METAL CHIP 15K 5% 1/10W
R104 1-216-839-11 METAL CHIP 33K 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R109 1-216-857-11 METAL CHIP 1M 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-857-11 METAL CHIP 1M 5% 1/10W
R113 1-216-857-11 METAL CHIP 1M 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-797-11 METAL CHIP 10 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian model
CND : Canadian model
KR : Korean model
MX : Mexican model
SP : Singapore model
TH : Thai model
To Next Page
