Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
44
HCD-M70
CD CONTROL
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-817-11 METAL CHIP 470 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-845-11 METAL CHIP 100K 5% 1/10W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-863-11 RES-CHIP 3.3M 5% 1/10W
R143 1-216-848-11 METAL CHIP 180K 5% 1/10W
R144 1-216-848-11 METAL CHIP 180K 5% 1/10W
R147 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R148 1-216-797-11 METAL CHIP 10 5% 1/10W
R149 1-216-797-11 METAL CHIP 10 5% 1/10W
R158 1-216-852-11 METAL CHIP 390K 5% 1/10W
R159 1-216-847-11 METAL CHIP 150K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R161 1-216-821-11 METAL CHIP 1K 5% 1/10W
R162 1-216-847-11 METAL CHIP 150K 5% 1/10W
R171 1-218-291-11 RES-CHIP 16K 5% 1/10W
R172 1-216-833-11 METAL CHIP 10K 5% 1/10W
R173 1-216-835-11 METAL CHIP 15K 5% 1/10W
R181 1-218-291-11 RES-CHIP 16K 5% 1/10W
R182 1-216-833-11 METAL CHIP 10K 5% 1/10W
R183 1-216-835-11 METAL CHIP 15K 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X101 1-781-947-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
A-4676-452-A CONTROL BOARD, COMPLETE (US, CND)
A-4676-462-A CONTROL BOARD, COMPLETE (MX)
A-4676-468-A CONTROL BOARD, COMPLETE (SP, AUS)
A-4728-251-A CONTROL BOARD, COMPLETE (AEP, UK)
A-4729-435-A CONTROL BOARD, COMPLETE (KR, TH)
************************
< CAPACITOR >
C314 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C315 1-126-947-11 ELECT 47uF 20% 35V
C316 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C388 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(AEP, UK)
C802 1-115-456-21 CAPACITOR 0.22F 5.5V
C803 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C804 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C806 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C807 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C808 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C809 1-115-156-11 CERAMIC CHIP 1uF 10V
C810 1-104-665-11 ELECT 100uF 20% 10V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C812 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C813 1-126-964-11 ELECT 10uF 20% 50V
C814 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C815 1-115-156-11 CERAMIC CHIP 1uF 10V
C816 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C817 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C820 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-126-963-11 ELECT 4.7uF 20% 50V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C827 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C829 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C830 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN801 1-784-776-11 CONNECTOR, FFC 15P
CN802 1-785-950-11 CONNECTOR, FFC/FPC 18P
CN803 1-785-949-11 CONNECTOR, FFC/FPC 20P
CN804 1-784-778-11 CONNECTOR, FFC 17P
CN805 1-784-780-11 CONNECTOR, FFC 19P
CN806 1-568-838-11 CONNECTOR, FFC 21P
* CN807 1-568-954-11 PIN, CONNECTOR 5P
* CN809 1-506-985-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D304 8-719-921-40 DIODE MTZJ-4.7C
D321 8-719-991-33 DIODE 1SS133T-77 (AEP, UK)
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-991-33 DIODE 1SS133T-77
< IC >
IC320 8-759-584-65 IC KA3082
IC801 8-752-930-03 IC CXP83124A-053Q
IC803 8-759-652-68 IC BMR-0301H
< RESISTOR >
JR801 1-216-864-11 METAL CHIP 0 5% 1/10W
JR803 1-216-864-11 METAL CHIP 0 5% 1/10W
JR804 1-216-864-11 METAL CHIP 0 5% 1/10W
JR805 1-216-864-11 METAL CHIP 0 5% 1/10W
JR806 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L301 1-410-324-11 INDUCTOR 4.7uH
L302 1-412-002-31 INDUCTOR CHIP 4.7uH
L303 1-412-002-31 INDUCTOR CHIP 4.7uH
L304 1-410-997-31 INDUCTOR CHIP 2.2uH
< TRANSISTOR >
Q800 8-729-055-94 TRANSISTOR SRC1202SF
Q801 8-729-055-94 TRANSISTOR SRC1202SF
Q802 8-729-055-91 TRANSISTOR SRA2202SF
Q803 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q804 8-729-055-94 TRANSISTOR SRC1202SF
< RESISTOR >
R308 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R309 1-216-797-11 METAL CHIP 10 5% 1/10W
