Sony HCD-M70 - Printed Wiring Board - SWITCH Board

HCD-M70
2828
6-14. PRINTED WIRING BOARD – SWITCH Board – • See page 17 for Circuit Boards Location.
D804 C-6
D805 B-6
D807 C-2
D808 B-2
D809 E-2
D810 E-4
D811 D-6
D812 E-6
D813 C-6
D814 B-7
IC802 D-2
Q805 D-4
Q806 D-5
Q807 D-6
Q808 D-4
Q809 D-6
Q810 D-6
Q811 D-6
• Semiconductor
Location
Ref. No. Location
IC802
H
SWITCH BOARD
CONTROL BOARD
CN802
G
CONTROL BOARD
CN803
F
CONTROL
BOARD
CN801
LIQUID CRYSTAL DISPLAY
(STANDBY)
D804, 805
(LCD BACK LIGHT)
D807, 808
(LCD BACK LIGHT)
1-684-229-
11
(11)
20
10
1
13
TUNING +
TUNING –
CD
REC
CD
CD
CD
TAPE
TAPE
VOLUME +
VOLUME –
TUNER
TUNER
FM
TUNER
AM
TAPE
DSG
D811,S808
FUNCTION
CD SYNCHRO
36
1
A
B
C
D
E
F
1 2 3 4 5 6 7
(Page 26)
(Page 26) (Page 26)
