Sony HCD-M70 - Printed Wiring Boards - MAIN;JACK Boards

HCD-M70
2424
6-11. PRINTED WIRING BOARDS – MAIN/JACK Boards – • See page 17 for Circuit Boards Location.
D302 B-2
D305 C-9
D307 F-7
D308 E-7
D309 C-8
D310 B-3
D311 G-7
D314 E-5
D315 B-10
D316 B-10
D320 B-9
D820 F-6
D821 F-6
IC101 E-9
IC201 F-9
IC304 F-7
IC306 B-5
IC323 B-6
IC324 D-3
IC326 B-9
Q100 C-7
Q200 C-7
Q301 B-8
Q302 B-8
Q303 C-8
Q304 C-9
Q305 E-7
Q306 D-7
Q307 E-6
Q308 E-6
Q309 C-2
Q310 C-9
Q311 C-9
Q312 E-2
Q313 D-2
Q330 C-7
Q341 B-2
Q342 B-2
Q343 B-2
Q344 B-2
Q355 G-7
Q406 D-3
Q407 D-3
Q408 D-3
Q409 D-2
• Semiconductor
Location
Ref. No. Location
IC306
IC323
IC201
IC101
IC304
IC326
IC324
1-684-231-
11
(11)
(CHASSIS)
(CHASSIS)
(CHASSIS)
(CHASSIS)
(US, CND, MX)
AEP, UK, SP,
KR, TH, AUS
15
PHONES
CD SYNCHRO
PLAY MODE
TUNING MODE
S819
REPEAT
FM MODE
S816
S810
DIRECTION
S814
E
CONTROL BOARD
CN804
B
TC BOARD
CN301
17
JACK BOARD
MAIN BOARD
17
16
21
TUNER UNIT
SUPPLIED WITH
THE ASSEMBLED BLOCK
TU1
L
R
AUDIO IN
MD (VIDEO)
L
R
+
–
–
+
SPEAKER
IMPEDANCE
USE 6 – 16Ω
C
CONTROL
BOARD
CN806
D
POWER
BOARD
CN101
SJ301
B
C
E
B
C
E
B
C
E
15
14
1
2
15
14
2
1
1-684-232-
11
(11)
A
B
C
D
E
F
G
1 2 3 4 5 6 7 8 9 10 11
(AEP, UK)
16
1
5
8
10
(Page 20)
(Page 26)
(Page 30)
(Page 26)
