Sony HCD-M70 - Printed Wiring Board - POWER Board

HCD-M70
3030
6-16. PRINTED WIRING BOARD – POWER Board – • See page 17 for Circuit Boards Location.
D902 D-5
D903 D-5
D904 C-5
D905 C-5
D906 C-6
D907 C-5
D908 D-6
D909 D-5
D910 C-3
D911 B-3
D912 C-3
D913 B-3
D915 B-5
D917 B-6
D918 C-4
Q901 B-6
Q902 C-4
Q903 B-5
• Semiconductor
Location
Ref. No. Location
MAIN POWER
TRANSFORMER
∗
SUB POWER
TRANSFORMER
(SP)
(EXCEPT SP)
(EXCEPT SP)
(SP)
MAIN BOARD
CNP101
D
1
2
1
8
(US, CND)
(EXCEPT SP)
(SP)
POWER BOARD
LINE
FILTER
EXCEPT
US, CND
EXCEPT
US, CND
(AC IN)
12
(CHASSIS)
(US, CND)
(US, CND)
G901
1-684-234-
11
(11)
–1 –2
VOLTAGE
SELECTOR
S901
110V – 120V
220V – 240V
A
B
C
D
E
F
G
H
1 2 3 4 5 6
(Page
24)
