Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
46
HCD-M70
R902 1-216-845-11 METAL CHIP 100K 5% 1/10W
R903 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R904 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-845-11 METAL CHIP 100K 5% 1/10W
R906 1-216-841-11 METAL CHIP 47K 5% 1/10W
R907 1-216-821-11 METAL CHIP 1K 5% 1/10W
R908 1-216-821-11 METAL CHIP 1K 5% 1/10W
R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
R910 1-216-821-11 METAL CHIP 1K 5% 1/10W
R911 1-216-821-11 METAL CHIP 1K 5% 1/10W
R912 1-216-821-11 METAL CHIP 1K 5% 1/10W
R913 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
< VIBRATOR >
X800 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X801 1-579-901-11 VIBRATOR, CERAMIC (4.19MHz)
**************************************************************
1-684-231-11 JACK BOARD
***********
< CAPACITOR >
C801 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(US, CND, MX)
< DIODE >
D820 8-719-988-61 DIODE 1SS355TE-17
(AEP, UK, SP, KR, TH, AUS)
D821 8-719-988-61 DIODE 1SS355TE-17
(AEP, UK, SP, KR, TH, AUS)
< FERRITE BEAD >
FB803 1-414-813-11 FERRITE 0uH
< JACK >
J301 1-794-453-11 JACK (PHONES)
< RESISTOR >
JR510 1-216-864-11 METAL CHIP 0 5% 1/10W
JR511 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L101 1-412-002-31 INDUCTOR CHIP 4.7uH
L201 1-412-002-31 INDUCTOR CHIP 4.7uH
L202 1-410-989-11 INDUCTOR CHIP 0.47uH
< RESISTOR >
R587 1-216-833-11 METAL CHIP 10K 5% 1/10W
R590 1-216-837-11 METAL CHIP 22K 5% 1/10W
R591 1-216-821-11 METAL CHIP 1K 5% 1/10W
R593 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S810 1-571-760-11 SWITCH, KEY BOARD (CD SYNCHRO)
S814 1-571-760-11 SWITCH, KEY BOARD (DIRECTION)
S816 1-571-760-11 SWITCH, KEY BOARD (REPEAT, FM MODE)
S819 1-571-760-11 SWITCH, KEY BOARD
(PLAY MODE, TUNING MODE)
**************************************************************
1-681-807-11 LOADING BOARD
**************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER SLIDE
(DISC TRAY OPEN/CLOSE DETECT)
**************************************************************
A-4676-457-A MAIN BOARD, COMPLETE (US, CND)
A-4676-466-A MAIN BOARD, COMPLETE (MX)
A-4676-473-A MAIN BOARD, COMPLETE (SP)
A-4728-254-A MAIN BOARD, COMPLETE (AEP, UK)
A-4729-441-A MAIN BOARD, COMPLETE (AUS)
A-4729-442-A MAIN BOARD, COMPLETE (KR)
A-4729-443-A MAIN BOARD, COMPLETE (TH)
*********************
4-217-354-11 BUSHING, INSULATING
4-230-078-01 SCREW, +BV TAPPING
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-163-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20% 50V
C106 1-126-163-11 ELECT 4.7uF 20% 50V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C110 1-126-963-11 ELECT 4.7uF 20% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-126-963-11 ELECT 4.7uF 20% 50V
C115 1-126-163-11 ELECT 4.7uF 20% 50V
C130 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C131 1-124-259-11 ELECT 4.7uF 20% 16V
C141 1-126-967-11 ELECT 47uF 20% 50V
C142 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C143 1-126-965-11 ELECT 22uF 20% 50V
C144 1-130-495-00 MYLAR 0.1uF 5% 50V
C145 1-130-495-00 MYLAR 0.1uF 5% 50V
C150 1-124-259-11 ELECT 4.7uF 20% 16V
C160 1-124-261-00 ELECT 10uF 20% 50V
C163 1-124-259-11 ELECT 4.7uF 20% 16V
C170 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(SP, AUS)
C170 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT SP, AUS)
C201 1-126-963-11 ELECT 4.7uF 20% 50V
C202 1-126-963-11 ELECT 4.7uF 20% 50V
C203 1-126-963-11 ELECT 4.7uF 20% 50V
C204 1-126-963-11 ELECT 4.7uF 20% 50V
