Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
49
HCD-M70
R350 1-249-425-11 CARBON 4.7K 5% 1/4W
R364 1-216-805-11 METAL CHIP 47 5% 1/10W
R371 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(AEP, UK)
R372 1-216-853-11 METAL CHIP 470K 5% 1/10W
(AEP, UK)
R373 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP, UK)
R374 1-216-845-11 METAL CHIP 100K 5% 1/10W
(AEP, UK)
R375 1-216-841-11 METAL CHIP 47K 5% 1/10W
(AEP, UK)
R376 1-216-843-11 METAL CHIP 68K 5% 1/10W
(AEP, UK)
R377 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP, UK)
R383 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< TERMINAL BOARD/JACK >
SJ301 1-816-048-11 TERMINAL BOARD (SPEAKER)
SJ302 1-815-045-11 JACK, PIN 2P (AUDIO IN MD (VIDEO))
< TERMINAL BOARD >
TH1 1-537-770-21 TERMINAL BOARD, GROUND
TH2 1-537-770-21 TERMINAL BOARD, GROUND
< TUNER UNIT >
TU1 A-4303-953-A TUNER UNIT (TCB-023//K (CE))
(AEP, UK, KR, AUS)
TU1 A-4303-954-A TUNER UNIT (TCB-023//K (UC))
(US, CND, MX, SP, TH)
< VIBRATOR >
X301 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
**************************************************************
A-4676-455-A POWER BOARD, COMPLETE (US, CND)
A-4676-464-A POWER BOARD, COMPLETE (MX)
A-4676-471-A POWER BOARD, COMPLETE (SP)
A-4728-252-A POWER BOARD, COMPLETE
(AEP, UK, KR, TH, AUS)
***********************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
C910 1-161-494-00 CERAMIC 0.022uF 25V
C911 1-126-947-11 ELECT 47uF 20% 35V
C917 1-126-934-11 ELECT 220uF 20% 16V
C918 1-126-964-11 ELECT 10uF 20% 50V
C920 1-104-666-11 ELECT 220uF 20% 25V
0 C925 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN101 1-766-281-11 PIN, CONNECTOR (PC BOARD) 8P
CN901 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D902 8-719-902-17 DIODE U15G
D903 8-719-902-17 DIODE U15G
D904 8-719-902-17 DIODE U15G
D905 8-719-902-17 DIODE U15G
D906 8-719-046-07 DIODE 2A02M
D907 8-719-046-07 DIODE 2A02M
D908 8-719-046-07 DIODE 2A02M
D909 8-719-046-07 DIODE 2A02M
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D915 8-719-109-97 DIODE RD6.8ES-B2
D917 8-719-991-33 DIODE 1SS133T-77
D918 8-719-109-93 DIODE RD6.2ES-B2
< FUSE >
0 F901 1-533-445-11 FUSE, GLASS TUBE (DIA. 5) (0.8A/125V)
(US, CND, MX)
0 F901 1-533-461-11 FUSE, GLASS TUBE (DIA. 5) (T0.4A/250V)
(AEP, UK, KR, TH, AUS)
0 F902 1-533-464-11 FUSE, GLASS TUBE (DIA. 5) (0.8A/250V) (SP)
0 F903 1-533-461-11 FUSE, GLASS TUBE (DIA. 5) (0.4A/250V) (SP)
0 F904 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) (T2A/250V)
(AEP, UK, SP, KR, TH, AUS)
0 F904 1-576-478-11 FUSE, GLASS TUBE (2A/125V) (US, CND, MX)
< TERMINAL BOARD >
G901 1-537-770-21 TERMINAL BOARD, GROUND (US, CND)
< LINE FILTER >
0 LF901 1-424-150-11 TRANSFORMER, LINE FILTER (US, CND)
< TRANSISTOR >
Q901 8-729-056-23 TRANSISTOR STC352-OY
Q902 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q903 8-729-056-23 TRANSISTOR STC352-OY
< RESISTOR >
R902 1-249-425-11 CARBON 4.7K 5% 1/4W
R904 1-249-425-11 CARBON 4.7K 5% 1/4W
R905 1-249-437-11 CARBON 47K 5% 1/4W
0 R909 1-219-237-11 SOLID 3.3M 20% 1/2W
(US, CND)
R910 1-249-409-11 CARBON 220 5% 1/4W
< RELAY >
0 RY901 1-755-332-11 RELAY
< SWITCH >
0 S901 1-786-152-11 SWITCH, SLIDE (VOLTAGE SELECTOR) (SP)
< TRANSFORMER >
0 T901 1-437-253-11 TRANSFORMER, POWER (SP)
0 T901 1-437-730-11 TRANSFORMER, POWER
(AEP, UK, KR, TH, AUS)
0 T901 1-437-731-11 TRANSFORMER, POWER (US, CND, MX)
0 T902 1-437-727-11 TRANSFORMER, POWER
(AEP, UK, KR, TH, AUS)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN POWER
