Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
52
HCD-M70
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
TC VIDEO
< COIL/TRANSFORMER >
T101 1-419-080-11 COIL
T201 1-419-080-11 COIL
T401 1-433-372-31 TRANSFORMER, BIAS OSCILLATION
< TERMINAL BOARD >
TH1 1-537-770-21 TERMINAL BOARD, GROUND
TH2 1-537-770-21 TERMINAL BOARD, GROUND
TH3 1-537-770-21 TERMINAL BOARD, GROUND
**************************************************************
1-684-235-11 VIDEO BOARD
************
< IC >
IC321 8-749-923-04 IC TOTX178A (OPTICAL DIGITAL OUT (CD))
***********************************************************
MISCELLANEOUS
**************
2 1-823-149-11 LEAD (WITH CONNECTOR)
58 1-926-063-20 FFC CABLE 20P
59 1-926-063-10 FFC CABLE 18P
60 1-926-065-20 FFC CABLE 15P
102 1-796-353-11 DECK, MECHANICAL (TAPE)
109 1-773-044-11 WIRE (FLAT TYPE) (17 CORE)
110 1-926-062-30 FFC CABLE 8P
157 1-926-063-50 FFC CABLE 21P
158 1-926-063-40 FFC CABLE 17P
202 1-684-233-11 POWER RETAINER BOARD
0 204 1-558-943-31 CORD, POWER (TH)
0 204 1-696-169-11 CORD, POWER (AEP, UK, SP)
0 204 1-696-848-41 CORD, POWER (AUS)
0 204 1-769-079-21 CORD, POWER (KR)
0 204 1-775-789-81 CORD, POWER (MX)
0 204 1-783-532-11 CORD, POWER (US, CND)
513 1-792-411-11 CABLE, FLEXIBLE FLAT (19 CORE)
0 553 A-4735-357-A OP BASE ASSY (KSM-213DHAP/ZRP1)
555 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
M901 A-2004-893-A MOTOR (LD) ASSY (LOADING)
************************************************************
ACCESSORIES
************
0 1-770-019-51 ADAPTOR, CONVERSION PLUG (UK)
