7
MD mechanism deck
CD mechanism deck
Main board
Power board
Amp board
CN802
Extension cable (4P)
(J-2501-042-A)
Extension cable (3P)
(J-2501-045-A)
CN993
SERVICE POSITION THE MD MECHANISM
SERVICE POSITION THE CD MECHANISM
SERVICE POSITION THE POWER BOARD
