103
HCD-RV777D/RV888D/RV999D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
0 R255 1-245-235-21 METAL 0.22 10% 2W F
0 R256 1-245-235-21 METAL 0.22 10% 2W F
R257 1-247-831-11 CARBON 1K 5% 1/4W
R258 1-249-431-11 CARBON 15K 5% 1/4W
R259 1-247-879-11 CARBON 100K 5% 1/4W
R260 1-260-076-11 CARBON 10 5% 1/2W F
0 R261 1-212-881-11 FUSIBLE 100 5% 1/4W F
R271 1-247-879-11 CARBON 100K 5% 1/4W
R272 1-247-879-11 CARBON 100K 5% 1/4W
0 R280 1-216-456-00 METAL OXIDE 820 5% 2W F
(RV888D/RV999D)
0 R280 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(RV777D)
R281 1-260-076-11 CARBON 10 5% 1/2W F
R282 1-260-076-11 CARBON 10 5% 1/2W F
R283 1-260-076-11 CARBON 10 5% 1/2W F
R284 1-260-076-11 CARBON 10 5% 1/2W F
R285 1-247-871-11 CARBON 47K 5% 1/4W
R286 1-247-871-11 CARBON 47K 5% 1/4W
R287 1-249-429-11 CARBON 10K 5% 1/4W
R288 1-247-871-11 CARBON 47K 5% 1/4W
R289 1-249-429-11 CARBON 10K 5% 1/4W
R290 1-249-429-11 CARBON 10K 5% 1/4W
R924 1-247-831-11 CARBON 1K 5% 1/4W
< RELAY >
RY281 1-515-920-11 RELAY
< THERMISTOR >
TH201 1-807-796-11 THERMISTOR
< TERMINAL BOARD >
TM201 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER)
*************************************************************
HP BOARD
*********
< JUMPER RESISTOR >
C500 1-216-864-11 SHORT CHIP 0
< CONNECTOR >
* CN503 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< JACK >
J502 1-794-702-11 JACK, HEADPHONE (PHONES)
< RESISTOR >
R531 1-260-083-11 CARBON 47 5% 1/2W F
R532 1-260-083-11 CARBON 47 5% 1/2W F
*************************************************************
A-1053-972-A JACK BOARD, COMPLETE (RV999D:E51,AR,MX)
A-4751-845-A JACK BOARD, COMPLETE
(EXCEPT RV999D:E51,AR,MX)
*********************
< CAPACITOR >
C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C504 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C507 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C508 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C509 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C510 1-115-868-11 ELECT 0.22uF 20% 50V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C512 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C513 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C514 1-115-867-11 ELECT 0.1uF 20% 50V
C515 1-115-872-11 ELECT 2.2uF 20% 50V
C516 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C517 1-162-955-11 CERAMIC CHIP 150PF 5% 50V
C518 1-115-872-11 ELECT 2.2uF 20% 50V
C519 1-126-791-11 ELECT 10uF 20% 35V
C520 1-126-786-11 ELECT 47uF 20% 16V
C521 1-126-786-11 ELECT 47uF 20% 16V
C522 1-115-871-11 ELECT 1uF 20% 50V
(EXCEPT RV999D:E51,AR,MX)
C523 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT RV999D:E51,AR,MX)
C524 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT RV999D:E51,AR,MX)
C525 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(EXCEPT RV999D:E51,AR,MX)
C526 1-115-870-11 ELECT 0.47uF 20% 50V
(EXCEPT RV999D:E51,AR,MX)
C527 1-115-870-11 ELECT 0.47uF 20% 50V
(EXCEPT RV999D:E51,AR,MX)
C528 1-131-664-11 CERAMIC CHIP 0.15uF 10% 10V
(EXCEPT RV999D:E51,AR,MX)
C529 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT RV999D:E51,AR,MX)
C530 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT RV999D:E51,AR,MX)
C531 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(EXCEPT RV999D:E51,AR,MX)
C532 1-126-785-11 ELECT 47uF 20% 10V
(EXCEPT RV999D:E51,AR,MX)
C533 1-126-785-11 ELECT 47uF 20% 10V
(EXCEPT RV999D:E51,AR,MX)
C534 1-115-871-11 ELECT 1uF 20% 50V
(EXCEPT RV999D:E51,AR,MX)
C535 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT RV999D:E51,AR,MX)
C536 1-115-872-11 ELECT 2.2uF 20% 50V
(EXCEPT RV999D:E51,AR,MX)
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
FRONT AMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
