104
HCD-RV777D/RV888D/RV999D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D1201 8-719-069-54 DIODE UDZSTE-175.1B
(EXCEPT RV999D:E51,AR,MX)
< GROUND TERMINAL BOARD >
EPT501 1-537-771-21 TERMINAL BOARD, GROUND
EPT502 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB505 1-469-869-21 INDUCTOR (EMI FERRITE) (2012)
< IC >
IC501 8-759-710-97 IC NJM4565M-D
IC502 8-759-496-41 IC M65850FP-E1
(EXCEPT RV999D:E51,AR,MX)
< JACK >
J501 1-764-592-11 JACK, 3P (GAME INPUT)
J503 1-770-226-11 JACK (LARGE TYPE) (MIC)
< RESISTOR >
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R503 1-216-841-11 METAL CHIP 47K 5% 1/10W
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R506 1-216-833-11 METAL CHIP 10K 5% 1/10W
R507 1-216-821-11 METAL CHIP 1K 5% 1/10W
R508 1-216-835-11 METAL CHIP 15K 5% 1/10W
R509 1-216-821-11 METAL CHIP 1K 5% 1/10W
R510 1-216-837-11 METAL CHIP 22K 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R512 1-216-833-11 METAL CHIP 10K 5% 1/10W
R513 1-216-847-11 METAL CHIP 150K 5% 1/10W
R514 1-216-809-11 METAL CHIP 100 5% 1/10W
R515 1-216-845-11 METAL CHIP 100K 5% 1/10W
R516 1-216-813-11 METAL CHIP 220 5% 1/10W
R517 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R518 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R519 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R520 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R521 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R523 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R524 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R525 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R526 1-216-846-11 METAL CHIP 120K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R527 1-216-814-11 METAL CHIP 270 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R528 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
R529 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EXCEPT RV999D:E51,AR,MX)
< VARIABLE RESISTOR >
RV501 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV502 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
(EXCEPT RV999D:E51,AR,MX)
*************************************************************
A-1053-866-A MAIN BOARD, COMPLETE (RV999D:SP,MY,PH)
A-1053-867-A MAIN BOARD, COMPLETE (RV999D:EA)
A-1053-868-A MAIN BOARD, COMPLETE (RV999D:AUS)
A-1053-869-A MAIN BOARD, COMPLETE
(RV999D:E51,AR,MX)
A-1053-871-A MAIN BOARD, COMPLETE (RV888D:SP,MY)
A-1053-872-A MAIN BOARD, COMPLETE (RV888D:EA)
A-1053-873-A MAIN BOARD, COMPLETE (RV888D:AUS)
A-1053-875-A MAIN BOARD, COMPLETE (RV777D:SP,MY,PH)
A-1053-876-A MAIN BOARD, COMPLETE (RV777D:EA)
A-4751-800-A MAIN BOARD, COMPLETE (RV999D:E3,E15)
A-4751-804-A MAIN BOARD, COMPLETE (RV888D:E3,E15)
A-4751-806-A MAIN BOARD, COMPLETE (RV777D:E3,E15)
*********************
< CAPACITOR >
C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C102 1-126-382-11 ELECT 100uF 20% 16V
C103 1-104-658-11 ELECT 100uF 20% 10V
C104 1-104-658-11 ELECT 100uF 20% 10V
C105 1-104-658-11 ELECT 100uF 20% 10V
C111 1-126-964-11 ELECT 10uF 20% 50V
C112 1-126-961-11 ELECT 2.2uF 20% 50V
C113 1-126-961-11 ELECT 2.2uF 20% 50V
C114 1-126-961-11 ELECT 2.2uF 20% 50V
C115 1-115-872-11 ELECT 2.2uF 20% 50V
C117 1-126-961-11 ELECT 2.2uF 20% 50V
C118 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C119 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C120 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C123 1-126-795-11 ELECT 10uF 20% 50V
C124 1-137-194-81 FILM 0.47uF 5% 50V
C125 1-137-194-81 FILM 0.47uF 5% 50V
C126 1-115-871-11 ELECT 1uF 20% 50V
C127 1-126-964-11 ELECT 10uF 20% 50V
C132 1-115-871-11 ELECT 1uF 20% 50V
C133 1-136-497-81 FILM 0.1uF 5% 50V
(RV777D)
C134 1-137-190-11 FILM 0.22uF 5% 50V
(RV777D)
C135 1-126-795-11 ELECT 10uF 20% 50V
C136 1-136-161-00 FILM 0.047uF 5% 50V
C137 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-964-11 ELECT 10uF 20% 50V
C142 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C143 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
JACK MAIN
